SECTION LOCATIONS
Top View
Bottom View
DISPLAY
PCB
5
LEFT METER
PCB
9
RIGHT METER
PCB
10
TUBE
PCB
11
HEADPHONE
PCB
8
AUDIO
PCB
4
OUTPUT
PCB
12
RIGHT
PUSHBUTTON
PCB
7
LEFT
PUSHBUTTON
PCB
6
CONTROL
PCB
2
DIGITAL
PCB
3
