McIntosh C2600 Service Manual

62
Ref. No. Description Part No.
CONTROL PCB 751898 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
2
D3 DIODE SCHOTTKY 40V 2A SMD 070210
D4 DIODE SCHOTTKY 40V 2A SMD 070210
D5 DIODE SCHOTTKY 40V 2A SMD 070210
D6 DIODE SCHOTTKY 40V 2A SMD 070210
D7 DIODE SCHOTTKY 40V 5A SMD 070212
D8 DIODE SCHOTTKY 40V 5A SMD 070212
D9 DIODE RECTIFIER 400V 1A SMD 070208
D10 DIODE RECTIFIER 400V 1A SMD 070208
D11 DIODE RECTIFIER 400V 1A SMD 070208
D12 DIODE RECTIFIER 400V 1A SMD 070208
D13 DIODE ESD SUPPRESSOR SMD 070198
D14 DIODE ESD SUPPRESSOR SMD 070198
D15 DIODE ESD SUPPRESSOR SMD 070198
D16 DIODE ESD SUPPRESSOR SMD 070198
D17 DIODE ESD SUPPRESSOR SMD 070198
D18 DIODE ESD SUPPRESSOR SMD 070198
D19 DIODE ESD SUPPRESSOR SMD 070198
D20 DIODE ESD SUPPRESSOR SMD 070198
D21 DIODE ESD SUPPRESSOR SMD 070198
D22 DIODE SMALL SIGNAL 4148 SMD 070199
D23 DIODE SMALL SIGNAL 4148 SMD 070199
D24 DIODE ESD SUPPRESSOR SMD 070198
D25 DIODE ESD SUPPRESSOR SMD 070198
D26 DIODE ESD SUPPRESSOR SMD 070198
D27 DIODE ESD SUPPRESSOR SMD 070198
D28 DIODE ESD SUPPRESSOR SMD 070198
D29 DIODE ESD SUPPRESSOR SMD 070198
D30 DIODE ESD SUPPRESSOR SMD 070198
D31 DIODE ESD SUPPRESSOR SMD 070198
D32 DIODE ESD SUPPRESSOR SMD 070198
D33 DIODE ESD SUPPRESSOR SMD 070198
D34 DIODE ESD SUPPRESSOR SMD 070198
D35 DIODE ESD SUPPRESSOR SMD 070198
D36 DIODE RECTIFIER 1000V 1A SMD 070225
D37 DIODE RECTIFIER 1000V 1A SMD 070225
D38 DIODE RECTIFIER 1000V 1A SMD 070225
D39 DIODE RECTIFIER 1000V 1A SMD 070225
D44 DIODE ZENER 10V 5% 0.35W SMD 070222
F2 FUSE 1/8A SLO-BLO 5X20 IEC 089128
FH1 HOLDER FUSE 5X20MM PCB MOUNT 178159
FH2 HOLDER FUSE 5X20MM PCB MOUNT 178159
GP1 TERMINAL PC MOUNT 4-40 118115
GP2 TERMINAL PC MOUNT 4-40 118115
GP3 TERMINAL PC MOUNT 4-40 118115
J1 CONN PCB MOUNT POWER RED 117719
J2 CONNECTOR 2 PIN HEADER 11.88MM 118026
J4 CONN PCB MOUNT POWER RED 117719
J6 CONN 23 PIN FFC SMD 118004
J7 CONN SHROUDED HEADER 2 X 8 117977
J8 CONN 12 PIN FFC SMD 118001
J9 CONN 18 PIN FFC SMD 118003
J10 CONN 18 PIN FFC SMD 118003
J11 JACK HEADPHONE DUAL BLACK 1/8” 117825
J12 JACK HEADPHONE DUAL BLACK 1/8” 117825
J13 JACK HEADPHONE DUAL BLACK 1/8” 117825
J14 JACK HEADPHONE DUAL BLACK 1/8” 117825
J15 JACK HEADPHONE DUAL BLACK 1/8” 117825
J16 JACK HEADPHONE DUAL BLACK 1/8” 117825
J17 JACK HEADPHONE DUAL BLACK 1/8” 117825
J18 HEADER 9 CIRCUIT POST NATURAL 117724
J19 CONN 8 PIN 2.5MM SHROUDED 118046
K1 RELAY 12VDC 5A 250VAC TV-4 087077
L1 FERRITE 60 OHM 5 AMP SMD 076025
L2 FERRITE 60 OHM 5 AMP SMD 076025
L3 FERRITE 60 OHM 5 AMP SMD 076025
L4 FERRITE 60 OHM 5 AMP SMD 076025
L5 FERRITE 60 OHM 5 AMP SMD 076025
L6 FERRITE 60 OHM 5 AMP SMD 076025
L7 FERRITE 60 OHM 5 AMP SMD 076025
L8 FERRITE 600 OHM 1 AMP SMD 076026
L9 FERRITE 600 OHM 1 AMP SMD 076026
L10 FERRITE 600 OHM 1 AMP SMD 076026
L11 FERRITE 600 OHM 1 AMP SMD 076026
L12 FERRITE 600 OHM 1 AMP SMD 076026
L13 FERRITE 600 OHM 1 AMP SMD 076026
L14 FERRITE 600 OHM 1 AMP SMD 076026
L15 FERRITE 600 OHM 1 AMP SMD 076026
L16 FERRITE 600 OHM 1 AMP SMD 076026
L17 FERRITE 600 OHM 1 AMP SMD 076026
L18 FERRITE 600 OHM 1 AMP SMD 076026
L19 FERRITE 600 OHM 1 AMP SMD 076026
L20 FERRITE 600 OHM 1 AMP SMD 076026
L21 FERRITE 600 OHM 1 AMP SMD 076026
L22 FERRITE 600 OHM 1 AMP SMD 076026
L23 FERRITE 600 OHM 1 AMP SMD 076026
L24 FERRITE 600 OHM 1 AMP SMD 076026
L25 FERRITE 600 OHM 1 AMP SMD 076026
L26 FERRITE 600 OHM 1 AMP SMD 076026
L27 FERRITE 600 OHM 1 AMP SMD 076026
L28 FERRITE 600 OHM 1 AMP SMD 076026
L29 FERRITE 600 OHM 1 AMP SMD 076026
L30 FERRITE 600 OHM 1 AMP SMD 076026
L31 FERRITE 600 OHM 1 AMP SMD 076026
PCB1 PC BD CONTROL 130325
Q1 TRANSISTOR NPN A05 SMD 132333
Q2 TRANSISTOR NPN A05 SMD 132333
Q3 TRANSISTOR NPN A05 SMD 132333
Q4 TRANSISTOR NPN A05 SMD 132333
Q5 TRANSISTOR NPN A05 SMD 132333
Q6 TRANSISTOR NPN A05 SMD 132333
Q7 TRANSISTOR NPN A05 SMD 132333
Q8 TRANSISTOR NPN A05 SMD 132333
Q9 TRANSISTOR NPN A05 SMD 132333
Q10 TRANSISTOR NPN A05 SMD 132333
Q11 TRANSISTOR NPN A05 SMD 132333
Q12 TRANSISTOR NPN A05 SMD 132333
Q13 TRANSISTOR NPN A05 SMD 132333
Q14 TRANSISTOR NPN A05 SMD 132333
Q15 TRANSISTOR NPN A05 SMD 132333
Q16 TRANSISTOR NPN A05 SMD 132333
Q17 TRANSISTOR NPN A05 SMD 132333
Q18 TRANSISTOR NPN A05 SMD 132333
Q19 TRANSISTOR NPN A05 SMD 132333
Q20 TRANSISTOR NPN A05 SMD 132333
Q21 TRANSISTOR NPN A05 SMD 132333
Q22 TRANSISTOR NPN A05 SMD 132333
Q23 TRANSISTOR NPN A05 SMD 132333
Q24 TRANSISTOR NPN A05 SMD 132333

McIntosh C2600 Specifications

General

Signal to Noise Ratio	100dB
Phono Stage	Yes
Digital USB Input	1
Digital MCT Input	1
Vacuum Tube	Yes
Type	Tube Preamplifier
Frequency Response	20Hz - 20kHz (+0, -0.5dB)
Phono Inputs	1 Moving Magnet 1 Moving Coil
Outputs	3 Total
Output Impedance	100 ohms
Dimensions	17.5" (44.45cm) x 6" (15.24cm) x 18" (45.72cm)
Headphone Output	1/4" High Drive with Headphone Crossfeed Director (HXD®)
