McIntosh C2600 Service Manual

C2600
Ref. No. Description Part No.
CONTROL PCB 751898 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
63
2
Q25 TRANSISTOR NPN A05 SMD 132333
Q26 TRANSISTOR NPN A05 SMD 132333
Q27 TRANSISTOR NPN A05 SMD 132333
Q28 TRANSISTOR NPN A05 SMD 132333
Q29 TRANSISTOR NPN A05 SMD 132333
Q30 TRANSISTOR NPN A05 SMD 132333
Q32 TRANSISTOR NPN A05 SMD 132333
Q33 TRANSISTOR NPN 300V BF420 132351
Q31 TRANSISTOR NCH MOSFET 800V SMD 132353
R1 FUSE 0.35A 16V RESET 1206 SMD 145054
R2 FUSE 0.35A 16V RESET 1206 SMD 145054
R3 POLYSWITCH 3.00A 72V 144722
R4 POLYSWITCH 3.00A 72V 144722
R5 POLYSWITCH 1.6A 72V 144757
R6 POLYSWITCH 1.6A 72V 144757
R7 RES SMD0805 150K 1/8W 1% 145037
R8 RES TF 100K 1% 0.1W SMD0805 145062
R9 RES SMD0805 1K 1/8W 1% 145007
R10 RES TF 47.5K 1% 0.125W SMD0805 145132
R11 RES TF 47.5K 1% 0.125W SMD0805 145132
R12 RES TF 47.5K 1% 0.125W SMD0805 145132
R13 RES SMD0805 22.1K 1/8W 1% 145012
R14 RES SMD0805 1K 1/8W 1% 145007
R15 RES SMD0805 18.2K 1/8W 1% 145031
R16 RES SMD0805 150K 1/8W 1% 145037
R17 RES SMD0805 150K 1/8W 1% 145037
R18 RES SMD0805 332K 1/8W 1% 145039
R19 RES TF 221K .125W .5% SMD0805 145140
R20 RES TF 221K .125W .5% SMD0805 145140
R21 RES TF 10K 1% 0.1W SMD0805 145061
R22 RES SMD0805 1.82K 1/8W 1% 145023
R23 RES SMD0805 332K 1/8W 1% 145039
R24 RES SMD0805 4.75K 1/8W 1% 145008
R25 RES SMD0805 4.75K 1/8W 1% 145008
R26 RES TF 10 1% 0.1W SMD0805 145063
R27 RES TF 22.1 .5% .1W SMD 145133
R28 RES TF 22.1 .5% .1W SMD 145133
R29 RES TF 22.1 .5% .1W SMD 145133
R30 RES TF 22.1 .5% .1W SMD 145133
R31 RES TF 22.1 .5% .1W SMD 145133
R32 RES TF 22.1 .5% .1W SMD 145133
R33 RES SMD0805 22.1K 1/8W 1% 145012
R34 RES SMD0805 1K 1/8W 1% 145007
R35 RES TF 22.1 .5% .1W SMD 145133
R36 RES SMD0805 22.1K 1/8W 1% 145012
R37 RES TF 47.5K 1% 0.125W SMD0805 145132
R38 RES TF 22.1 .5% .1W SMD 145133
R39 RES SMD0805 22.1K 1/8W 1% 145012
R40 RES TF 47.5K 1% 0.125W SMD0805 145132
R42 RES SMD0805 4.75K 1/8W 1% 145008
R43 RES SMD0805 4.75K 1/8W 1% 145008
R44 RES TF 10K 1% 0.1W SMD0805 145061
R45 RES SMD0805 22.1K 1/8W 1% 145012
R46 RES SMD0805 22.1K 1/8W 1% 145012
R47 RES SMD0805 22.1K 1/8W 1% 145012
R48 RES TF 2.21K 1% 0.1W SMD0805 145126
R49 RES SMD0805 4.75K 1/8W 1% 145008
R50 RES SMD0805 4.75K 1/8W 1% 145008
R51 RES TF 22.1 .5% .1W SMD 145133
R52 RES TF 22.1 .5% .1W SMD 145133
R53 RES TF 22.1 .5% .1W SMD 145133
R54 RES TF 22.1 .5% .1W SMD 145133
R55 RES TF 22.1 .5% .1W SMD 145133
R56 RES TF 22.1 .5% .1W SMD 145133
R57 RES TF 10 1% 0.1W SMD0805 145063
R58 RES TF 10 1% 0.1W SMD0805 145063
R59 RES TF 10 1% 0.1W SMD0805 145063
R60 RES TF 10 1% 0.1W SMD0805 145063
R61 RES TF 10 1% 0.1W SMD0805 145063
R62 RES TF 10 1% 0.1W SMD0805 145063
R63 RES TF 100 1% 0.1W SMD0805 145060
R64 RES TF 100 1% 0.1W SMD0805 145060
R65 RES TF 100 1% 0.1W SMD0805 145060
R66 RES TF 100 1% 0.1W SMD0805 145060
R67 RES TF 100 1% 0.1W SMD0805 145060
R68 RES TF 100 1% 0.1W SMD0805 145060
R69 RES SMD0805 1.5K 1/8W 1% 145022
R70 RES SMD0805 22.1K 1/8W 1% 145012
R71 RES SMD0805 22.1K 1/8W 1% 145012
R72 RES SMD0805 22.1K 1/8W 1% 145012
R73 RES SMD0805 22.1K 1/8W 1% 145012
R74 RES SMD0805 22.1K 1/8W 1% 145012
R75 RES SMD0805 22.1K 1/8W 1% 145012
R76 RES TF 47.5K 1% 0.125W SMD0805 145132
R77 RES SMD0805 22.1K 1/8W 1% 145012
R78 RES SMD0805 475K 1/8W 1% 145040
R79 RES SMD0805 22.1K 1/8W 1% 145012
R80 RES SMD0805 22.1K 1/8W 1% 145012
R81 RES SMD0805 22.1K 1/8W 1% 145012
R82 RES SMD0805 22.1K 1/8W 1% 145012
R83 RES SMD0805 22.1K 1/8W 1% 145012
R84 RES TF 2.21K 1% 0.1W SMD0805 145126
R85 RES SMD0805 3.32K 1/8W 1% 145026
R86 RES TF 2.21K 1% 0.1W SMD0805 145126
R87 RES SMD0805 3.32K 1/8W 1% 145026
R88 RES TF 2.21K 1% 0.1W SMD0805 145126
R89 RES SMD0805 3.32K 1/8W 1% 145026
R90 RES TF 2.21K 1% 0.1W SMD0805 145126
R91 RES SMD0805 3.32K 1/8W 1% 145026
R92 RES TF 2.21K 1% 0.1W SMD0805 145126
R93 RES SMD0805 3.32K 1/8W 1% 145026
R94 RES SMD0805 4.75K 1/8W 1% 145008
R95 RES SMD0805 4.75K 1/8W 1% 145008
R96 RES SMD0805 4.75K 1/8W 1% 145008
R97 RES SMD0805 4.75K 1/8W 1% 145008
R98 RES SMD0805 4.75K 1/8W 1% 145008
R99 RES SMD0805 22.1K 1/8W 1% 145012
R100 RES TF 47.5K 1% 0.125W SMD0805 145132
R101 RES SMD0805 22.1K 1/8W 1% 145012
R102 RES SMD0805 22.1K 1/8W 1% 145012
R103 RES TF 22.1 .5% .1W SMD 145133
R104 RES TF 22.1 .5% .1W SMD 145133
R105 RES TF 22.1 .5% .1W SMD 145133
R106 RES TF 22.1 .5% .1W SMD 145133
R107 RES TF 22.1 .5% .1W SMD 145133
R108 RES SMD0805 22.1K 1/8W 1% 145012
R109 RES SMD0805 22.1K 1/8W 1% 145012
R110 RES SMD0805 22.1K 1/8W 1% 145012

McIntosh C2600 Specifications

General

Signal to Noise Ratio	100dB
Phono Stage	Yes
Digital USB Input	1
Digital MCT Input	1
Vacuum Tube	Yes
Type	Tube Preamplifier
Frequency Response	20Hz - 20kHz (+0, -0.5dB)
Phono Inputs	1 Moving Magnet 1 Moving Coil
Outputs	3 Total
Output Impedance	100 ohms
Dimensions	17.5" (44.45cm) x 6" (15.24cm) x 18" (45.72cm)
Headphone Output	1/4" High Drive with Headphone Crossfeed Director (HXD®)
