PERFORMANCE LIMITS
Performance limits are the maximum deviation from
perfection permitted for a Mclntosh instrument. We
promise you that when you purchase a new C 34V from
a Mclntosh franchised dealer, it will be capable of or
can be made capable of performance at or exceeding
these limits or you can return the unit and get your
money back. Mclntosh is the only manufacturer that
makes this statement.
PREAMPLIFIER SECTION
FREQUENCY RESPONSE
+ 0, -0.5dB from 20Hz to 20,000Hz
MAXIMUM VOLTAGE OUTPUT
10 volts from 20Hz to 20,000Hz
TOTAL HARMONIC DISTORTION
0.01% maximum from 20Hz to 20,000Hz
at rated output
SENSITIVITY
Phono- 2mV for 2.5V rated output
(0.4mV IHF)
High Level- 250mV for 2.5V rated output
(50mV IHF)
SIGNAL TO NOISE RATIO, A-WEIGHTED
Phono- 90dB below 10mV input
(84dB IHF)
High Level- 100dB below rated output
(86dB IHF)
MAXIMUM INPUT SIGNAL
Phono- 100mV
High Level- 10 volts
INPUT IMPEDANCE
Phono- 47k ohms and 65pf capacitance
High Level- 50k ohms
EQUALIZATION CONTROLS
Variable 12dB boost to 12dB cut at center frequen-
cies of 30, 150, 500, 1500, 10k Hz
COMPANDOR RATIOS
From 1:2 compression to 2:1 expansion
LF FILTER
Flat or roll-off at 12dB per octave below 50 Hz.
HF FILTER
Flat or roll-off at 12dB per octave above 7,000 Hz.
MONITOR AMPLIFIER SECTION
CONTINUOUS AVERAGE POWER OUTPUT
20 watts per channel into 8 ohms, from 20Hz to
20kHz, at 0.01% maximum harmonic distortion
FREQUENCY RESPONSE
+ 0 -0.2dB from 20Hz to 20,000Hz
SENSITIVITY
750mV for rated output (170mV IHF), input im-
pedance is 27K ohms
SIGNAL TO NOISE RATIO, A-WEIGHTED
100dB below rated output (87dB IHF)
GENERAL INFORMATION
SEMICONDUCTOR COMPLEMENT
31 Bipolar Transistors
76 Field Effect Transistors
35 Integrated Circuits
107 Diodes
1 Silicon Controlled Rectifier (SCR 2)
AC POWER OUTLETS
1 green turntable current sensing, 100 watts
2 red unswitched
3 black switched
1440 watts total capacity
POWER REQUIREMENTS
120 volts, 50/60 Hz, 25 to 85 watts
MECHANICAL INFORMATION
SIZE:
16-1/8 inches wide (40.6 cm) by 5-7/16 inches high
(13.8 cm) by 13 inches deep (33 cm), from the
mounting surface, including PANLOC shelf and back
panel connectors. Knob clearance required is 1-1/4
inches (3.2 cm) in front of the mounting panel.
FINISH:
Front panel is anodized gold and black with special
gold/teal nomenclature illumination. Chassis is black.
MOUNTING:
Exclusive Mclntosh developed professional PANLOC
WEIGHT:
26 pounds (11.8 kg) net, 38 pounds (17.2 kg) in
shipping carton
PERFORMANCE LIMITS 15
