McIntosh C48 User Manual

14
1. Press and hold the EQ BYPASS/SETUP Push-
button until the Setup Mode is active. Then press
the OUTPUT 2 / MENU ► Push-button to select
the Setup Menu item “SETUP: SOURCE INPUT,
TUNER :RCA”. Refer to figure 4.
2. Rotate the INPUT Control until “CD2 : RCA”
appears on the Front Panel Information Display.
Refer to figure 5.
3. Rotate the VOLUME/ADJUST Control until “CD2
: BALANCED 1” appears on the Front Panel In-
formation Display. Refer to figure 6.
The second example will illustrate reassigning the
SRVR (Server) Input from SRVR/REC Input (RCA
Jacks) to the DIGital 1 Optical Input.
4. Rotate the INPUT Control until “SRVR : RCA”
appears on the Front Panel Information Display.
Refer to figure 7.
Reassign Source Inputs, con’t
Figure 6
SETUP: SOURCE INPUT
CD2 : BALANCED 1
Figure 5
SETUP: SOURCE INPUT
CD2 : RCA
Figure 7
SETUP: SOURCE INPUT
SRVR : RCA
SETUP: SOURCE INPUT
SRVR : DIGITAL 1
Figure 8
Input Level Adjustment
Source Components can have slightly different volume
levels resulting in the need to readjust the C48 Volume
Control when switching between different sources.
The C48 allows the adjustment of levels for each of
the Source Inputs for the same relative volume. The
CD and SERVER Inputs are used in the following
example.
Note: The range of adjustment is ± 6dB. The signal Level
present at the RECORD OUT Jacks is unaffected
by any changes in the Setup Level adjustment. The
level adjustments made are retained in permanent
memory. They can be changed during operation
of the C48 by performing a Trim Level Procedure,
refer to page 19 for additional information.
1. Rotate the INPUT Control to select the CD Input
and adjust the VOLUME Control to the desired
listening level.
2. Press and hold the EQ BYPASS/SETUP Push-
button until the Setup Mode is active. Then press
the OUTPUT 2 / MENU ► Push-button until the
Setup Menu item “LEVEL: CD 0.0dB” appears
on the Front Panel Information Display. Refer to
figure 9.
Note: The CD Input is serving as a reference level
or choose another source frequently listened
to. The Input Source should be set to a refer-
ence Level (Trim) of 0.0dB.
3. Rotate the INPUT Control until “LEVEL: SRVR
0.0dB” appears on the Front Panel Information
Display. If necessary, rotate the VOLUME/AD-
JUST Control to obtain the same volume level
as the CD Input by switching between the two
Inputs using the INPUT Control.
Figure 9
LEVEL: CD 0.0dB
Min Max
||
Figure 4
SETUP: SOURCE INPUT
TUNER : RCA
5. Rotate the VOLUME/ADJUST Control until
“SRVR : DIGITAL 1” appears on the Front Panel
Information Display. Refer to figure 8. Record
any changes made to the various inputs from the
default settings in the “Input and Power Control
Settings” chart for future reference.
6. To exit from the Setup Mode, press the EQ BY-
PASS/SETUP Push-button.

McIntosh C48 Specifications

General

Amplifier class	-
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	0.002 %
XLR in	Yes
XLR out	4
USB 2.0 ports quantity	1
Purpose	Home
Product color	Black
Connectivity technology	Wired
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	30 W

Weight and Dimensions

Depth	457.2 mm
Width	444.5 mm
Height	152.4 mm
Weight	12000 g
