McIntosh C48 User Manual

16
appears on the Front Panel Alphanumeric Display.
Refer to figure 14.
3. Press the EQ BYPASS/SETUP Push-button to exit
the Setup Mode.
5. Rotate the VOLUME/ADJUST Control until “Ac-
tion: SOURCE” appears. Refer to figure 17.
6. Then press the OUTPUT 2 / MENU ► Push-
button until the Setup Menu item “SETUP: TRIG1
OUTPUT, Source: _ _ _ _ _ _ _ _ OFF” appears
on the Front Panel Information Display. Refer to
figure 18.
Note: By default all the Source Inputs are set to Off.
7. Rotate the INPUT Control to select the Tuner as
the source. Refer to figure 18.
8. Rotate the VOLUME/ADJUST Control until
“Source: Tuner ON” appears. Refer to figure 19.
9. Press the EQ BYPASS/SETUP Push-button to exit
the Setup Mode.
Figure 17
SETUP: TRIG1 OUTPUT
Action: SOURCE
Figure 18
SETUP: TRIG1 OUTPUT
Source: Tuner OFF
Figure 19
SETUP: TRIG1 OUTPUT
Source: Tuner ON
Power Control Triggers 1 and 2
By default the Power Control TRIGger 1 and TRIG-
ger 2 Outputs function the same as the MAIN Power
Control Jack, switching On/Off with the C48. Trigger
1 and 2 are also reassignable to activate when the ACC
ON/OFF Push-buttons on the Remote Control are used
or when a given Input or Inputs are selected.
In the first example, the Power Control Trigger 1
Output will be set to function via the Remote Control
ACC Push-buttons.
1. Press and hold the EQ BYPASS/SETUP Push-
button until the Setup Mode is active. Then press
the OUTPUT 2 / MENU ► Push-button until the
Setup Menu item “SETUP: TRIG1 OUTPUT, Ac-
tion: MAIN” appears on the Front Panel Informa-
tion Display. Refer to figure 15.
2. Rotate the VOLUME/ADJUST Control until “Ac-
tion: REMOTE” appears. Refer to figure 16.
3. Press the EQ BYPASS/SETUP Push-button to exit
the Setup Mode.
The second example will use selection of the Tuner
Input to switch the Trigger 1 Output On.
4. Press and hold the EQ BYPASS/SETUP Push-
button until the Setup Mode is active. Then press
the OUTPUT 2 / MENU ► Push-button until the
Setup Menu item “SETUP: TRIG1 Output, Ac-
tion: MAIN” appears on the Front Panel Informa-
tion Display. Refer to figure 15.
Figure 15
SETUP: TRIG1 OUTPUT
Action: MAIN
Figure 16
SETUP: TRIG1 OUTPUT
Action: REMOTE
SETUP: PASSTHRU
Source: BALANCED 2
Figure 14
Passthru, con’t

McIntosh C48 Specifications

General

Amplifier class	-
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	0.002 %
XLR in	Yes
XLR out	4
USB 2.0 ports quantity	1
Purpose	Home
Product color	Black
Connectivity technology	Wired
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	30 W

Weight and Dimensions

Depth	457.2 mm
Width	444.5 mm
Height	152.4 mm
Weight	12000 g
