McIntosh MA352 User Manual

27
Packing Instructions
Packing Instructions
MA352 Packing Material List
Quantity Part Number Description
1 034614 Shipping carton
1 034615 Foam Top
1 034617 Foam Bottom
4 034616 Foam Middle
1 034613 Foam Insert (for protecting
the Tubes during shipping)
1 241001 Warning Sheet
4 400159 10-32 x 3/4 inch screw
4 017937 Feet
In the event it is necessary to repack the equipment
for shipment, the equipment must be packed exactly
as shown below. It is very important that the four feet
are attached to the bottom of the equipment. This will
ensure the proper equipment location on the bottom
foam pad. Failure to do this will result in shipping
damage.
To protect the tubes during shippment, the Foam
Insert removed from the MA352 needs to be re-insert-
ed. Follow the unpacking instructions on pages 4-5 in
the reverse order.
Use the original shipping carton and interior parts
only if they are all in good serviceable condition. If
a shipping carton or any of the interior part(s) are
needed, please call or write Customer Service Depart-
ment of McIntosh Laboratory, refer to page 2. Please
see the Part List for the correct part numbers.
Foam Top
Shipping Carton
Warning Sheet
Foam Bottom
Foam Middle (4)
Foam Insert for
Tubes and Shields
Accessories
Plastic Foot (4)
10/32 X 3/4” Screw
With Washer (4)

McIntosh MA352 Specifications

General

Total Harmonic Distortion	0.03%
Number of Channels	2
Speaker Impedance	4, 8 Ohms
Rated Power Band	20Hz to 20kHz
Headphone Output	Yes
Home Theater PassThru	Yes
Type	Integrated Amplifier
Input Impedance (Line)	20K ohms
Input Impedance (MM)	47K ohms, 50pF
Frequency Response	+0, -0.5dB from 20Hz to 20kHz
Signal to Noise Ratio	100dB
Preamplifier Inputs	1 Balanced
Variable Output	1
Phono Input	Moving Magnet
Vacuum Tube or Solid State	Hybrid (Vacuum Tube and Solid State)
Vacuum Tube Complement	2 x 12AX7A, 1 x 12AT7
Input Sensitivity	0.5V (Balanced)
Input Impedance	20K ohms Balanced, 20K ohms Unbalanced
