McIntosh MA5300 User Manual

12
5. Connect the MA5300 power cord to an active AC
outlet.
Spade Lug or Wire Connections:
6. Connect the Loudspeaker hookup cables to the
MA5300 Negative Output Terminal and Positive
Output Terminal to the Loudspeaker Terminal
Connections being careful to observe the cor-
rect polarities. Insert the spade lug connector or
prepared section of the cable end into the terminal
side access hole, and tighten the terminal cap until
the cable is firmly clamped into the terminals so
the lugs or wire cannot slip out. Refer to figures L
and M.
Note: The illustration located on the separate folded
sheet “Mc2B” is for connection to an 8Ω
(ohms) Loudspeaker.
Refer to “General Information” Note 6 on page 3
for additional information.
WARNING: Loudspeaker terminals are hazard-
ous live and present a risk of electric
shock. For additional instruction on
making Loudspeaker Connections con-
tact your McIntosh Dealer or McIn-
tosh Technical Support.
7. Connect the MA5300 power cord to an active AC
outlet.
Connecting Loudspeakers
Figure L
Figure M

McIntosh MA5300 Specifications

General

Power Output per Channel	100 Watts
Number of Channels	2
Total Harmonic Distortion	0.005%
Input Impedance	20K ohms
Speaker Impedance Taps	8 Ohms, 4 Ohms
Preamplifier Output	Yes
Tone Controls	Bass and Treble
Home Theater PassThru	Yes
Headphone Output	Yes
Bluetooth	No
Frequency Response	20Hz to 20kHz
Rated Power Band	20Hz to 20kHz
Damping Factor	Greater than 200
Digital Inputs	2 Coaxial, 2 Optical, 1 USB
Digital-to-Analog Converter (DAC)	Yes
Input Sensitivity	2.5mV (MM)
DAC Resolution	32-Bit
Dimensions	17.5" (44.45cm) x 6" (15.24cm) x 22" (55.88cm)
