McIntosh MA8900 User Manual

5
Dimensions
Dimensions
The following dimensions can assist in determining
the best location for your MA8900. There is additional
information on the next page pertaining to installing
the MA8900 into cabinets.
Front View of the MA8900
Rear View of the MA8900
Side View of the MA8900
17- 1/2 "
44.5cm
7 - 5/8 "
19.4cm
3/16 "
0.5cm
16- 1/16 "
40.8cm
7 - 1/8 "
18.1cm
29/32 "
1.8cm
6"
15.2cm
12- 3/16 "
31cm
18- 3/4 "
47.6cm
16- 1/2 "
41.9cm
6- 1/4 "
15.9cm
1"
2.5cm
13"
33cm
1- 5/8 "
4.1cm
USB 35%
DSD256

McIntosh MA8900 Specifications

General

Power Output per Channel (8 Ohms)	200 Watts
Power Output per Channel (4 Ohms)	200 Watts
Number of Channels	2
Total Harmonic Distortion	0.005%
Input Impedance	20k ohms
Speaker Impedance Taps	4, 8 Ohms
Rated Power Band	20Hz to 20kHz
Headphone Output	Yes
Home Theater PassThru	Yes
Tone Controls	Bass and Treble
Tone Bypass	Yes
High Drive Headphone Amplifier	Yes
Digital USB Input	1
Digital Coaxial Input	2
Digital Optical Input	2
Digital MCT (DIN) Input	1
Power Output per Channel	200 Watts
Frequency Response	+0, -0.5dB from 20Hz to 20, 000Hz
Dimensions (W x H x D)	17.5 x 9.5 x 22 inches
Weight	75 lbs (34 kg)
Dynamic Headroom	2.0dB
Damping Factor	>40
Preamplifier Inputs	1 Balanced, 6 Unbalanced
Variable Outputs	1 unbalanced, 1 balanced
Power Requirement	120V 50/60Hz
Digital Input Sample Rate	192kHz
Standby Power Requirement	<0.5 Watts
Digital Input Bit Depth	Up to 32-bit
