Installation
The installation of the MC2000 Tube Power Ampli-
fier in your system consists of three main steps:
1. Unpacking the MC2000 along with accessories
from their shipping cartons.
2. Installation of the vacuum tubes and the protec-
tive tube cover.
3. Finally, the physical placement of the MC2000 in
your system.
Note: Two pairs of white gloves have been provided to
prevent fingerprinting of the MC2000 during
handling. It is also recommended the gloves be
used during the installation of the Vacuum Tubes
into the MC2000.
Unpacking the Amplifier and Accessories
The MC2000 Amplifier and accessories have been
packaged in specially designed shipping cartons, to
Installation
protect them from potential shipping damage and al-
low for easy removal from the cartons. Please refer to
the following steps.
Caution: The MC2000 Amplifier weight is 135
pounds (61.2 kilograms). It requires two or
more persons to safely handle when moving
the amplifier.
Unpacking the Amplifier:
1. Remove the shipping carton banding strap(s), if
any.
Note: If these banding straps are metal, use caution
as the straps are under tension and may have
sharp edges when cut.
2. Lift off the top of the outer shipping carton.
3. Lower the side flaps of the outer shipping car-
ton.
4. Lift off the top of the inner shipping carton.
5. Lower the side flaps of the inner shipping car-
ton.
6. Lift off the individual layers of foam packing
material from the MC2000. Refer to figure 1.
7. Put on the pair of white gloves (this will pre-
vent fingerprinting of the MC2000 during
handling).
8. Remove the plastic shipping bag.
Unpacking the Accessories:
1. Open the outer shipping carton.
2. Remove the inner carton from the outer ship-
ping carton.
3. Open the inner carton. Refer to figure 2.
4. Remove the accessories from the inner carton.
Figure 1
Foam Layers
Inner Carton
Plastic Bag
MC2000
Amplifier
Figure 2
Tube Cover
Tube Cover
fastening
screws
Tube Box
Screwdriver
Power Cord
Inner Carton
Adjustment tool
