McIntosh MC402

13
Mono Parallel Hookup Connections
Loudspeaker
Impedance
Loudspeaker Negative
Connection
Loudspeaker Positive
Connection
1
S
(Ohm)
Left an d Righ t Out put 2
S
- (Negative) Conn ect ion
Left an d Right Out put 2
S
+ (Posit ive) Connection
2
S
(Ohm)
Left an d Righ t Out put 4
S
- (Negative) Connect ion
Left an d Right Out put 4
S
+ (Posit ive) Connection
4
S
(Ohm)
Left an d Righ t Out put 8
S
- (Negative) Conn ect ion
Left an d Right Out put 8
S
+ (Posit ive) Connection
How to Connect for Mono Parallel
To AC
Outlet
Loudspeaker
System
4 ohm
McIntosh Audio Control Center
Jumper
Cables
