McIntosh MC501

9
How to Connect
To AC Outlet
4 ohm
Loudspeaker
McIntosh MX134 A/V Control Center
Caution: The Loudspeaker Negative Connections are above chassis
ground. Do not combine any connections together, ground
them or connect with another MC501.
MC501 Top Rear View
