PARTS LIST
23
Part No. Description Reference No.
049368 HEATSINK
061300 MONO CAP 100PF 100V 5% NPO T&R C7 C8
061304 MONO CAP .01UF 50V 5% X 7R T&R C9 C16
061305 MONO CAP .1UF 50V 5% Z50 T&R C3 C5
064363 CAP POLYPROP 0.15MF 10% 250VDC C10
066446 CAP ELECT 47MF 35V C1 C2
070047 SILICON DIODE 1N4148 T&R D1 D2 D3 D4 D5
070133 DIODE 200V,6A D6 D7
117213 2-PIN MALE CONNECTOR J4-
117217 MALE CONN 7 PIN J1-
117404 HEADER 2-PIN 0.156 J2-
117708 FASTON BLADE W/FEET J4
117712 FASTON BLADE .110 J5
132171 TRANSISTOR NPN Q1
132172 TRANSISTOR SI PNP MPSA55 Q2
132285 TRANSISTOR NPN 25C3334C Q6
132286 TRANSISTOR PNP 2SA32IC Q7
134390 TRIM POT 200 OHM 20% HORIZ AD R13
137093 MET OX 680 5% .5W R2 R9
137094 MET OX 1.8K 5% .5W R6 R11
137095 MET OX 430 5% .5W R7
137096 MET OX 47 5% .5W R12
139177 WIREWOUND RES 0.5 OHM 5W 5% R31 R32 R33 R34 R35 R36
R37 R38 R40 R41 R42 R43
144071 RES MF 365 1% 1/4W R1 R8
144187 RES MF 22.1K 1% 1/4W R3 R10
144243 RES WW 0.1 5% 1W R39
144249 THERMAL SENSOR RT1
144378 RES MF 2.21 OHM 1/4W 1% R30
049369 DRIVER
061002 DISC CAP 1.8PF+/-.25PF NPO C42 C43
061199 DISC CAP 100PF 10% N1500 50V C2 C3 C4 C5 C6 C7 C8 C9
061248 DISC CAP .1MF,25V,Y5T C1 C10
061256 M.CAP 470PF,5%,100V C26 C27 C28 C29
064308 CAP MPOLY .0047UF 5% 63-250VDC C34 C35 C36 C37
064316 CAP M POLY .022UF 5% 63VDC C38 C39
064363 CAP POLYPROP 0.15MF 10% 250VDC C30 C31 C32 C33
064364 CAP POLYPROP .047MF 10% 250V C22 C23 C24 C25
066244 CAP ELECT 0.47UF 50V 20% C20 C21
066327 CAP ELECT 470UF 10V C40 C41
066446 CAP ELECT 47MF 35V C15 C18
066462 CAP ELECT 1OUF 100VDC C11 C12 C13 C14 C16 C17 C19
117215 4-PIN CONNECTOR J8 J9
117217 MALE CONN 7 PIN J1- J2- J3- J4-
117219 MALE CONN 10 POS J7-
117279 11-POS. MALE CONN. J6-
132222 N. CHANNEL FET Q2 Q3 Q5 Q6 Q7 Q8 Q10 Q11
132223 TRANSISTOR NPN MPS4124 2K/REEL Q12 Q13 Q17 Q19 Q24 Q25 Q29
Q31 Q36 Q67 Q70 Q78 Q80
132224 TRANSISTOR PNP Q1 Q16 Q20 Q22 Q23 Q28 Q32
Q34 Q35 Q37 Q38 Q39 Q59 Q66
132254 TRANSISTOR NPN Q14 Q18 Q26 Q30 Q60 Q63 Q64
Q71 Q74 Q75 Q76 Q77
132255 TRANSISTOR PNP Q15 Q21 Q27 Q33 Q61 Q62 Q65
Q68 Q69 Q72 Q73 Q79
132285 TRANSISTOR NPN 25C3334C Q55 Q56 Q57 Q58
132286 TRANSISTOR PNP 2SA32IC Q40 Q41 Q42 Q43
133260 DUAL OPERATIONAL AMPLIFIER IC1
137042 FLAMEPROOF RES 47 OHM 5% 1/4W R3 R27 R74 R80
139005 WIRE RES 2 OHMS 10% 5W R110 R112 R114 R116
139119 WIRE RES 4 OHMS 5% 5W R109 R111 R113 R115
144015 RES MF 33.2K 1% 1/4W R104 R106 R107 R108
144028 RES MF 866 1% 1/4W R2 R4 R30 R57 R64 R65 R83 R91
144071 RES MF 365 1% 1/4W R17 R18 R19 R20 R21 R22 R23 R29
R42 R43 R44 R45 R46 R47 R48 R67
144090 RES MF 1K 1% 1/4W R60 R86
144095 RES MF 3.32K 1% 1/4W R53 R69 R72 R75 R92 R95 R97 R98
144097 RES MF 4.75K 1% 1/4W R58 R84
144108 RES MF 47.5K 1% 1/4W R61 R63 R87 R90
144113 RES MF 100K 1% 1/4W R76 R77 R78 R79
144128 RES MF 1.5K 1% 1/4W R10 R12 R35 R37
144172 RES MF 221 1% 1/4W R6 R24 R31 R49 R150 R151 R152
R153
144179 LDR NETWORK VTL5C9 LDR1 LDR2
144187 RES MF 22.1K 1% 1/4W R7 R32 R101
144196 RES MF 100 1% 1/4W R5 R62 R89 R100
144265 RES MF 2.21M 1/4W R9 R15 R34 R40
144298 RES MF 2.21K 1% 1/4W R103 R105
144338 RES MF 324 OHM 1% 1/4W R16 R41 R66 R71 R73 R88 R93 R99
144352 RES MF 174K 1% 1/4W R14 R39 R59 R85
144364 RES MF 475K 1% 1/4W R8 R33 R55 R81
144398 METAL FILM RES 3.79K .5% 1/4W R11 R25 R38 R50
144401 RES MF 6.49K .5% 1/4W R13 R26 R36 R51
144443 METAL FILM RES 681K 1% 1/4W R68 R70 R94 R96
049222 INPUT
061191 DISC CAP 22PF,10%,NPO 50V C11 C12
061196 DISC CAP 47PF,20%,N470 50V C7 C8
061248 DISC CAP .1MF,25V,Y5T C9 C10
066445 ELECT CAP 10MF, 50V AMMO PACK C1 C2 C4 C6
117219 MALE CONN 10 POS J7-
117436 PJ261G PHON JACK, GOLD J2-
117494 MINI JACK J11- J12-
117685 XLR RECEPTACLE FEMALE J3 J4
133260 DUAL OPERATIONAL AMPLIFIER IC1
141025 RES CF 100 5% 1/4W R130
144053 RES MF 10K 1% 1/4W R131 R133 R135 R138 R140 R142
144352 RES MF 174K 1% 1/4W R132 R136 R137 R139
148059 SLIDE SWITCH S1
049367 CAPACITOR
117404 HEADER 2-PIN 0.156 J1 J2 J3 J4
117708 FASTON BLADE W/FEET J5 J6 J7 J8 J9 J10 J11 J12
049384 METER
061305 MONO CAP .1UF 50V 5% Z50 T&R C14 C21 C22 C25 C26
064329 CAP M POLY .22UF 5% 63VDC C15 C16 C28
064337 CAP M POLY 1MF 5% 63VDC C11 C12
066289 CAP ELECT 4.7UF 10% 35V C27
066309 CAP ELECT 1000UF 10V C1 C2
066361 CAP ELECT 1000UF 20% 35V C30 C31
066506 CAP ELECT 22UF 100V C29
070047 SILICON DIODE 1N4148 T&R D1 D2 D3 D4 D5 D6 D7 D9 D10
D13 D14 D15 D16 D17 D18 D19
D21 D22 D23 D24 D25 D28
070085 ZENER DIODE 6.2V 5% 500MW D27
070114 ZENER DIODE 16V 5% 500MW D26 D29
070131 DIODE RECTIFIER D30 D31 D32
080014 HEATSINK T0220 ATTACH TO Q10 Q11 Q12
087049 RELAY 48VDC VFB48HU ITT TAKAMI K1
089089 FUSE 2A SLO-BLO 5X20 F1
117214 MALE CONN 3-POS MTS100 NORMAL J8-
117215 4-PIN CONNECTOR J10-
117217 MALE CONN 7 PIN J9-
24
117279 11-POS. MALE CONN J1- J2-
117708 FASTON BLADE W/FEET J12 J15 J16
131021 TRIAC 8A 200V Q12
131022 600V TRIAC DRIVER OPTOCOUPLER Q23
132223 TRANSISTOR NPN MPS4124 2K/REEL Q1 Q2 Q13 Q14 Q15 Q16 Q17 Q20
132224 TRANSISTOR PNP Q18 Q22
132226 TRANSISTOR P.CHANNEL JUNC.FET Q19
132242 TRANSISTOR POWER N-CHN Q10 Q11
132254 TRANSISTOR NPN Q8 Q9 Q24 Q25
133093 IC REGULATOR +5 VOLT Q21
133155 IC REGULATOR -12V IC7
133156 IC REGULATOR 12V IC6
133189 IC OPERATIONAL AMPLIFIER IC2 IC4
133192 IC NAND SCHMIT 2-IN X 4 IC5
133260 DUAL OPERATIONAL AMPLIFIER IC3
134383 TRIM POT 100K OHM 20% R1 R2
139079 WIRE RES 1.5K 10% 5W R68
139218 2.7 OHM 2W 5% WW RESISTOR FP R69
141023 RES CF 8.2 5% 1/4W R35 R39
144015 RES MF 33.2K 1% 1/4W R6 R17
(R61 & R62 ARE FOR CONVERSION)
144083 RES MF 5.11K 1% 1/4W R47
144091 RES MF 1.1K 1% 1/4W R60
144095 RES MF 3.32K 1% 1/4W R50
144097 RES MF 4.75K 1% 1/4W R4 R42
144108 RES MF 47.5K 1% 1/4W R44
144117 RES MF 200K 1% 1/4W R7 R11 R23 R37
144154 RES MF 12.1K 1% 1/4W R45 R51 R66
144181 RES MF 18.2K 1% 1/4W R9 R33
144187 RES MF 22.1K 1% 1/4W R5 R14 R55 R57
144195 RES MF 681 1% 1/4W R58 R67
144196 RES MF 100 1% 1/4W R10 R34 R56
144199 RES MF 3.16K 1% 1/4W R43 R48
144210 RES MF 7.5K 1% 1/4W R65
144264 RES MF 10M 1% 1/4W R8 R32
144269 RES MF 1M 1/4W R54 R59
144271 RES MF 2.74M 1/4W R12 R41 R64
144296 RES MF 1.82K 1% 1/4W R63
144364 RES MF 475K 1% 1/4W R71 R72
144406 METAL FILM RES 187K 1% 1/4W R46 R49 R52 R53
144419 MF RES 150K 1% 1/4W R30 R31 R36 R40 R70
159215 CURRENT TRANSFORMER T1 T2
178159 FUSE HOLDER 5X20MM PCB MOUNT F1
049371 INDICATOR
058120 LAMP 14V #7373 DS1 DS2 DS9 DS13
117213 2-PIN MALE CONNECTOR J6- J7-
117215 4-PIN CONNECTOR J4- J9-
117279 11-POS. MALE CONN. J3-
049370 PG LIGHT
058133 AMBER LED D1 D2
117215 4-PIN CONNECTOR J10-
049373 METER LAMPS
058120 LAMP 14V #7373 DS3 DS4 DS5 DS6 DS8 DS10
DS12 DS14
117215 4-PIN CONNECTOR J2-
049395 STANDBY LIGHT
058148 RED LED HIGH EFFICIENCY DS15
117215 4-PIN CONNECTOR J8-
