Ref. No. Description Part No.
DATA PCB 750562 Cont’d.
Ref. No. Description Part No.
PARTS LIST Cont’d.
C27 CAP ELECT 47UF 35V 066446
C28 CAP MONO 470PF 100V 10% NPO 061343
C30 CAP MONO 220PF 200V 10% NPO 061342
C35 CAP MONO .1UF 50V 20% Z5U 061346
C40 CAP MONO 220PF 200V 10% NPO 061342
C41 CAP MONO 220PF 200V 10% NPO 061342
C36 CAP MONO .1UF 50V 20% Z5U 061346
D20 DIODE SILICON 070174
D21 DIODE SILICON 070174
RIVET 1/8X3/16 STEEL 108011
IC1 IC 2 INPUT X 4 133591
IC2 IC 2 INPUT X 4 133591
IC3 IC NOR 2 INPUT X 4 133592
IC4 IC AND 2 INPUT X 4 133577
IC5 IC SHFT REG SER-PAR 133594
IC6 IC SHFT REG SER-PAR 133594
IC7 IC SHFT REG SER-PAR 133594
IC8 IC SHFT REG SER-PAR 133594
IC9 IC SHFT REG SER-PAR 133594
IC10 IC 8 LN DRIVER ARRAY 133180
(IC10) IC SOCKET 18 PIN DIP 178184
IC11 IC 8 LN DRIVER ARRAY 133180
(IC11) IC SOCKET 18 PIN DIP 178184
IC12 IC 8 LN DRIVER ARRAY 133180
(IC12) IC SOCKET 18 PIN DIP 178184
IC23 IC LINE RECEIVER QUAD 133428
IC24 IC 2 INPUT X 4 133591
IC25 IC HEX UNBUF INVERTER 133576
IC35 IC 8 LN DRIVER ARRAY 133180
(IC35) IC SOCKET 18 PIN DIP 178184
IC40 IC 8-INPUT SEL/MULTI 133219
J1 CONN MALE 7 PIN 117217
J2 CONN 4 PIN 117215
J3 CONN MALE 6 POS FRICTION LOCK 117218
J5_ CONN MALE 9 POS FRICTION LOCK 117244
J8 JACK MINI 117494
J9 JACK MINI 117494
J10 JACK MINI 117494
J11 JACK MINI 117494
J12 JACK MINI 117494
J13 JACK MINI 117494
J14 JACK MINI 117494
J15 JACK MINI 117494
J16 JACK MINI 117494
J17 JACK MINI 117494
J18 JACK MINI 117494
J19 JACK MINI 117494
J20 JACK MINI 117494
J21 JACK MINI 117494
J22 JACK MINI 117494
J30 CONN 4 PIN 117215
J32 CONN MALE 7 PIN 117217
J37 CONN MALE 10 POS RIGHT ANGLE 117260
J36 JACK RCA 4X1 ORANGE 14MM 117778
L1 INDUCTOR 3.9UH 5% 122400
L2 CHOKE 18UH 5%-10% 122394
L3 CHOKE 18UH 5%-10% 122394
L4 CHOKE 18UH 5%-10% 122394
L5 CHOKE 18UH 5%-10% 122394
L6 CHOKE 18UH 5%-10% 122394
L7 CHOKE 18UH 5%-10% 122394
L8 CHOKE 18UH 5%-10% 122394
L9 CHOKE 18UH 5%-10% 122394
L10 CHOKE 18UH 5%-10% 122394
OPT1 FIBER OPTIC RECEIVER 058179
OPT2 FIBER OPTIC RECEIVER 058179
OPT3 FIBER OPTIC RECEIVER 058179
OPT4 TRANSMITTER FIBER OPTIC 058180
PCB1 PC BD DATA 129774
R1 RES NETWORK 5 X 100 ISO 144677
R2 RES NETWORK 5 X 100 ISO 144677
R3 RES NETWORK 5 X 100 ISO 144677
R5 RES MF 100K 1% 1/4W 144528
R6 RES MF 100K 1% 1/4W 144528
R7 RES MF 100K 1% 1/4W 144528
R8 RES MF 100K 1% 1/4W 144528
R10 RES MF 100K 1% 1/4W 144528
R11 RES MF 100K 1% 1/4W 144528
R20 RES MF 1K 1% 1/4W 144513
R30 RES MF 75 OHM 1% 1/4W 144644
R31 RES MF 75 OHM 1% 1/4W 144644
R32 RES MF 75 OHM 1% 1/4W 144644
R33 RES MF 365 OHM 1% 1/4W 144505
R34 RES MF 95.3 OHM 1% 1/4W 144572
R40 RES MF 10K 1% 1/4W 144504
R60 RES MF 100K 1% 1/4W 144528
R61 RES MF 1K 1% 1/4W 144513
R63 RES MF 100K 1% 1/4W 144528
T1 TRANSFORMER DIGITAL INTERFACE 159351
U1 IC REGULATOR 12V 133590
5 S-VIDEO PCB 750564
C3 CAP MONO .1UF 50V 20% Z5U 061346
C4 CAP MONO .1UF 50V 20% Z5U 061346
C7 CAP MONO .1UF 50V 20% Z5U 061346
C8 CAP MONO .1UF 50V 20% Z5U 061346
C9 CAP MONO .1UF 50V 20% Z5U 061346
C10 CAP MONO .1UF 50V 20% Z5U 061346
C11 CAP MONO .1UF 50V 20% Z5U 061346
C13 CAP MONO .1UF 50V 20% Z5U 061346
C14 CAP MONO .1UF 50V 20% Z5U 061346
C15 CAP MONO .1UF 50V 20% Z5U 061346
C16 CAP ELECT 10UF 50V 066445
C17 CAP ELECT 10UF 50V 066445
C21 CAP MONO .1UF 50V 20% Z5U 061346
C22 CAP MONO .1UF 50V 20% Z5U 061346
C24 CAP MONO .1UF 50V 20% Z5U 061346
C26 CAP MONO .1UF 50V 20% Z5U 061346
C29 CAP MONO .1UF 50V 20% Z5U 061346
C30 CAP MONO .1UF 50V 20% Z5U 061346
C31 CAP MONO .1UF 50V 20% Z5U 061346
C32 CAP MONO .1UF 50V 20% Z5U 061346
C34 CAP MONO .1UF 50V 20% Z5U 061346
C36 CAP MONO .1UF 50V 20% Z5U 061346
C46 CAP MONO .1UF 50V 20% Z5U 061346
C47 CAP ELECT 10UF 50V 066445
C48 CAP ELECT 10UF 50V 066445
C49 CAP ELECT 10UF 50V 066445
C50 CAP ELECT 10UF 50V 066445
C51 CAP ELECT 10UF 50V 066445
80
