Ref. No. Description Part No.
COMPONENT VIDEO PCB 750566 Cont’d.
Ref. No. Description Part No.
PARTS LIST Cont’d.
L10 BEADS FERRITE LEADED 076023
L11 CHOKE RF 3.3UH 10% 122398
L12 RES CF 0 OHM 5% 1/4W 141554
L13 CHOKE 8.2UH 10% CC 122399
L18 INDUCTOR 2.7UH 122395
L19 INDUCTOR 2.7UH 122395
L20 INDUCTOR 2.7UH 122395
L21 INDUCTOR 2.7UH 122395
L22 INDUCTOR 2.7UH 122395
L23 INDUCTOR 2.7UH 122395
Q4 IC VOLTAGE REGULATOR -5.2V 133567
R1 RES MF 18.2 OHM 1% 1/4W 144659
R2 RES MF 4.75K 1% 1/4W 144520
R5 RES NETWORK 8 X 330 ISO 144679
R9 RES MF 10K 1% 1/4W 144504
R10 RES MF 10K 1% 1/4W 144504
R11 RES MF 10K 1% 1/4W 144504
R14 RES MF 806 OHM 1% 1/4W 144512
R15 RES MF 806 OHM 1% 1/4W 144512
R20 RES MF 75 OHM 1% 1/4W 144644
R22 RES MF 75 OHM 1% 1/4W 144644
R23 RES MF 75 OHM 1% 1/4W 144644
R24 RES MF 22.1K 1% 1/4W 144564
R25 RES MF 75 OHM 1% 1/4W 144644
R26 RES MF 806 OHM 1% 1/4W 144512
R27 RES MF 75 OHM 1% 1/4W 144644
R28 RES MF 4.75 OHM 1% 1/4W 144658
R29 RES MF 22.1 OHM 1% 1/4W 144554
R30 RES MF 10K 1% 1/4W 144504
R31 RES MF 10 OHM 1% 1/4W 144553
R32 RES MF 10 OHM 1% 1/4W 144553
R33 RES MF 22.1 OHM 1% 1/4W 144554
R35 RES MF 18.2 OHM 1% 1/4W 144659
R36 RES MF 56.2 OHM 1% 1/4W 144660
R37 RES MF 18.2 OHM 1% 1/4W 144659
R38 RES MF 56.2 OHM 1% 1/4W 144660
R39 RES MF 18.2 OHM 1% 1/4W 144659
R40 RES MF 56.2 OHM 1% 1/4W 144660
R41 RES MF 18.2 OHM 1% 1/4W 144659
R42 RES MF 56.2 OHM 1% 1/4W 144660
R43 RES MF 18.2 OHM 1% 1/4W 144659
R44 RES MF 56.2 OHM 1% 1/4W 144660
R45 RES MF 18.2 OHM 1% 1/4W 144659
R46 RES MF 56.2 OHM 1% 1/4W 144660
R50 RES MF 1.1K 1% 1/4W 144514
R53 RES MF 100K 1% 1/4W 144528
R54 RES MF 10K 1% 1/4W 144504
R55 RES MF 10 OHM 1% 1/4W 144553
R60 RES FP 10 OHM 5% 1/4W 137105
R61 RES MO 4.7 OHM 5% 1W 144656
R62 RES MO 4.7 OHM 5% 1W 144656
R63 RES MF 806 OHM 1% 1/4W 144512
R65 RES MF 4.75K 1% 1/4W 144520
R66 RES MF 4.75K 1% 1/4W 144520
R70 RES MF 10K 1% 1/4W 144504
R71 RES MF 10K 1% 1/4W 144504
R72 RES MF 10K 1% 1/4W 144504
R73 RES MF 806 OHM 1% 1/4W 144512
R74 RES MF 806 OHM 1% 1/4W 144512
R75 RES MF 10K 1% 1/4W 144504
R76 RES MF 806 OHM 1% 1/4W 144512
R77 RES MF 806 OHM 1% 1/4W 144512
R78 RES MF 75 OHM 1% 1/4W 144644
R79 RES MF 75 OHM 1% 1/4W 144644
R80 RES MF 75 OHM 1% 1/4W 144644
R88 RES MF 100K 1% 1/4W 144528
R89 RES MF 4.75K 1% 1/4W 144520
R90 RES MF 4.75K 1% 1/4W 144520
R91 RES MF 10K 1% 1/4W 144504
R92 RES MF 10K 1% 1/4W 144504
R94 RES CF 0 OHM 5% 1/4W 141554
R96 RES CF 0 OHM 5% 1/4W 141554
R98 RES MF 56.2 OHM 1% 1/4W 144660
R99 RES MF 18.2 OHM 1% 1/4W 144659
U2 IC QUAD ANALOG SWITCH HI SPEED 133342
Y1 CRYSTAL 17.7344 FUND 180076
Y2 CRYSTAL 27MHZ 3RD HARMONIC 180080
Y3 CRYSTAL 24.576MHZ 180075
Y4 CRYSTAL 14.3181MHZ FUND 180078
SCR MS 6-32X1/4 PH PN CLR 400186
NUT KEP 6-32 SPECIAL 402045
9 TUNER/RAA1 SECTION PCB 049084
C1 MONO CAP 0.1MF 20% 50V 061277
C2 MONO CAP 100PF 5% 100V NPO 061275
C3 MONO CAP 10PF 10% 100V 061288
C4 MONO CAP 0.1MF 20% 50V 061277
C5 MONO CAP .0022UF 10% 50V 061287
C6 MONO CAP 100PF 5% 100V NPO 061275
C7 MONO CAP 0.1MF 20% 50V 061277
C8 CAP MONO 22PF 5% 100V NPO 061282
C9 MONO CAP 10PF 10% 100V 061288
C10 CAP MONO .047UF 10% 50V X7R 061286
C11 MONO CAP 0.1MF 20% 50V 061277
C12 MONO CAP 100PF 5% 100V NPO 061275
C13 CAP MONO .047UF 10% 50V X7R 061286
C14 MONO CAP 100PF 5% 100V NPO 061275
C15 CAP MONO .047UF 10% 50V X7R 061286
C16 CAP MONO .047UF 10% 50V X7R 061286
C17 MONO CAP 100PF 5% 100V NPO 061275
C18 CAP MONO .047UF 10% 50V X7R 061286
C19 MONO CAP 0.1MF 20% 50V 061277
C20 MONO CAP 0.1MF 20% 50V 061277
C21 CAP MONO CER 360PF 5% 100V 061257
C22 MONO CAP 10PF 10% 100V 061288
C23 CAP MONO .0022UF 5% 100V NPO 061287
C25 CAP MONO .0022UF 5% 100V NPO 061287
C24 CAP MONO 22PF 5% 100V NPO 061282
C25 CAP MONO .0022UF 5% 100V NPO 061287
C26 MONO CAP 0.1MF 20% 50V 061277
C27 MONO CAP 0.1MF 20% 50V 061277
C28 CAP MONO .047UF 10% 50V X7R 061286
C29 MONO CAP 0.1MF 20% 50V 061277
C30 MONO CAP 0.1MF 20% 50V 061277
C31 CAP MONO .0022UF 5% 100V NPO 061287
C32 MONO CAP 10PF 10% 100V 061288
C33 CAP MONO .047UF 10% 50V X7R 061286
C34 MONO CAP 0.1MF 20% 50V 061277
C35 DISC CAP 1.8PF +/-.25PF NPO 061002
C36 M POLY CAP .015UF 5% 63V DC 064314
C37 M POLY CAP .033UF 5% 63V DC 064318
C38 M POLY CAP .047UF 5% 63V DC 064320
MX136
