28 IMM AGS-2
Table 20, Physical Data, AGS 165C – AGS 195C
AGS MODEL NUMBER
165C 175C 195C
DATA
Ckt 1 Ckt 2 Ckt 1 Ckt 2 Ckt 1 Ckt 2
BASIC DATA
Unit Cap. @ 44°F LWT, 95°F Ambient
Temperature kW, (tons)
160.5 (564) 172.5 (607) 190.3 (669)
Unit Operating Charge lbs (kg) 186 (84) 186 (84) 186 (84) 186 (84) 201 (91) 201 (91)
Cabinet Dimensions
L x W x H, in. (mm)
263 x 89 x 101
6680 x 2261 x 2565
263 x 89 x 101
6680 x 2261 x 2565
263 x 89 x 101
6680 x 2261 x 2565
Unit Operating Weight, lbs. (kg) 11928 (5415) 11277 (5120) 11277 (5120)
Unit Shipping Weight, lbs (kg) 11011 (4999) 11011 (4999) 11011 (4999)
Economizer N0 N0 Yes
COMPRESSORS, SCREW, SEMI-HERMETIC
Nominal Capacity, tons (kW) 70 (246) 85 (299) 85 (299) 85 (299) 95 (334) 95 (334)
CONDENSERS, HIGH EFFICIENCY FIN AND TUBE TYPE WITH INTEGRAL SUBCOOLER
Pumpdown Capacity, lbs (kg) 438 (199) 438 (199) 438 (199) 438 (199) 438 (199) 438 (199)
CONDENSER FANS, DIRECT DRIVE PROPELLER TYPE
No. of Fans – 30 in. Fan Dia. 12 12 12
No. of Motors -- hp (kW) 12 2 (1.5) 12 2 (1.5) 12 2 (1.5)
Fan & Motor RPM, 60Hz 1140 1140 1140
60 Hz Fan Tip Speed, fpm (m/s) 8950 (4224) 8950 (4224) 8950 (4224)
60 Hz Total Unit Airflow, cfm (l/s) 130360 (61530) 130360 (61530) 130360 (61530)
EVAPORATOR, DIRECT EXPANSION SHELL AND TUBE
Shell Dia.-Tube Length
in.(mm) - in. (mm)
19.4 x 105.1
(493 x 2670)
19.4 x 105.1
(493 x 2670)
19.4 x 105.1
(493 x 2670)
Evaporator R-134a Charge lbs (kg) 3.16 (1.4) 3.16 (1.4) 3.16 (1.4) 3.16 (1.4) 3.16 (1.4) 3.16 (1.4)
Water Volume, gallons (liters) 106 (401) 106 (401) 106 (401)
Max. Water Pressure, psi (kPa) 152 (1048) 152 (1048) 152 (1048)
Max. Refrigerant Press., psi (kPa) 352 (2427) 352 (2427) 352 (2427)
