40 IMM AGS-2
WIRING TO UNIT POWER BLOCK
TERMINAL SIZE (AMPS) CONNECTOR WIRE RANGE PER PHASE (COPPER WIRE ONLY)
AGS
UNIT
SIZE
VOLTS HZ
CKT 1 CKT 2 CKT 1 CKT 2
208 800 800 1/0 – 750 MCM (4/C) 1/0 – 750 MCM (4/C)
230 800 800 1/0 – 750 MCM (4/C) 1/0 – 750 MCM (4/C)
190 380 60 400 400 #6 – 350 MCM (2/C) #6 – 350 MCM (2/C)
460 400 400 #6 – 350 MCM (2/C) #6 – 350 MCM (2/C)
575 400 400 #6 – 350 MCM (2/C) #6 – 350 MCM (2/C)
208 800 800 1/0 – 750 MCM (4/C) 1/0 – 750 MCM (4/C)
230 800 800 1/0 – 750 MCM (4/C) 1/0 – 750 MCM (4/C)
195 380 60 400 400 #6 – 350 MCM (2/C) #6 – 350 MCM (2/C)
460 400 400 #6 – 350 MCM (2/C) #6 – 350 MCM (2/C)
575 400 400 #6 – 350 MCM (2/C) #6 – 350 MCM (2/C)
208 800 800 1/0 – 750 MCM (4/C) 1/0 – 750 MCM (4/C)
230 800 800 1/0 – 750 MCM (4/C) 1/0 – 750 MCM (4/C)
210 380 60 400 400 #6 – 350 MCM (2/C) #6 – 350 MCM (2/C)
460 400 400 #6 – 350 MCM (2/C) #6 – 350 MCM (2/C)
575 400 400 #6 – 350 MCM (2/C) #6 – 350 MCM (2/C)
NOTES:
1. Terminal size amps are the maximum amps that the power block is rated for.
2. See Table 26 for multiple point with Disconnect Switch connections.
3. Data based on 75°C wire.
4. (2/C) notation means two cables per conduit.
5. Complete notes are on page 47.
Table 26, AGS 120C –210C, Wiring Data with Multiple-Point Power w/ Disconnect Switch
WIRING TO UNIT DISCONNECT SWITCH (MOLDED CASE SWITCH)
TERMINAL SIZE (AMPS) CONNECTOR WIRE RANGE PER PHASE (COPPER WIRE ONLY)
AGS
UNIT
SIZE
VOLTS HZ
CKT 1 CKT 2 CKT 1 CKT 2
208 400 400 3/0 – 500 MCM (2/C) 3/0 – 500 MCM (2/C)
230 400 400 3/0 – 500 MCM (2/C) 3/0 – 500 MCM (2/C)
120 380 60 250 250 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
460 250 250 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
575 150 150 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
208 400 400 3/0 – 500 MCM (2/C) 3/0 – 500 MCM (2/C)
230 400 400 3/0 – 500 MCM (2/C) 3/0 – 500 MCM (2/C)
125 380 60 250 250 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
460 250 250 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
575 150 150 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
208 400 400 3/0 – 500 MCM (2/C) 3/0 – 500 MCM (2/C)
230 400 400 3/0 – 500 MCM (2/C) 3/0 – 500 MCM (2/C)
130 380 60 250 250 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
460 250 250 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
575 150 150 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
208 400 400 3/0 – 500 MCM (2/C) 3/0 – 500 MCM (2/C)
230 400 400 3/0 – 500 MCM (2/C) 3/0 – 500 MCM (2/C)
135 380 60 250 250 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
460 250 250 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
575 150 150 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
208 400 400 3/0 – 500 MCM (2/C) 3/0 – 500 MCM (2/C)
230 400 400 3/0 – 500 MCM (2/C) 3/0 – 500 MCM (2/C)
140 380 60 250 250 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
460 250 250 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
575 150 150 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
208 400 400 3/0 – 500 MCM (2/C) 3/0 – 500 MCM (2/C)
230 400 400 3/0 – 500 MCM (2/C) 3/0 – 500 MCM (2/C)
145 380 60 250 250 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
460 250 250 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
575 150 150 #6 – 350 MCM (1/C) #6 – 350 MCM (1/C)
Continued on next page
