IMM AGS-2 59
Table 35, Spring Vibration Isolators, AGS 120C – 210C, Copper Fin (Remote Evaporator)
Mounting Location
AGS
Model
M1 M2 M3 M4 M5 M6 Kit Number
CP2-31 CP2-31 CP2-28 CP2-28 CP1-31 CP1-31
120
GRAY GRAY GREEN GREEN WHITE WHITE
330904122
CP2-31 CP2-31 CP2-31 CP2-31 CP2-31 CP2-31
125
GRAY GRAY GRAY GRAY GRAY GRAY
330904123
CP2-31 CP2-31 CP2-28 CP2-28 CP1-31 CP1-31
130
GRAY GRAY GREEN GREEN WHITE WHITE
330904122
CP2-31 CP2-31 CP2-31 CP2-31 CP2-31 CP2-31
135
GRAY GRAY GRAY GRAY GRAY GRAY
330904123
CP2-31 CP2-31 CP2-28 CP2-28 CP1-31 CP1-31
140
GRAY GRAY GREEN GREEN WHITE WHITE
330904122
CP2-31 CP2-31 CP2-31 CP2-31 CP2-31 CP2-31
145
GRAY GRAY GRAY GRAY GRAY GRAY
330904123
CP2-31 CP2-31 CP2-28 CP2-28 CP1-31 CP1-31
160
GRAY GRAY GREEN GREEN WHITE WHITE
330904122
CP2-32 CP2-32 CP2-31 CP2-31 CP2-31 CP2-31
165
WHITE WHITE GRAY GRAY GRAY GRAY
330904105
CP2-31 CP2-31 CP2-31 CP2-31 CP2-31 CP2-31
170
GRAY GRAY GRAY GRAY GRAY GRAY
330904123
CP2-32 CP2-32 CP2-31 CP2-31 CP2-31 CP2-31
175
WHITE WHITE GRAY GRAY GRAY GRAY
330904105
CP2-31 CP2-31 CP2-31 CP2-31 CP2-31 CP2-31
180
GRAY GRAY GRAY GRAY GRAY GRAY
CP2-31 CP2-31 CP2-31 CP2-31 CP2-31 CP2-31
190
GRAY GRAY GRAY GRAY GRAY GRAY
330904123
CP2-32 CP2-32 CP2-31 CP2-31 CP2-31 CP2-31
195
WHITE WHITE GRAY GRAY GRAY GRAY
CP2-32 CP2-32 CP2-31 CP2-31 CP2-31 CP2-31
210
WHITE WHITE GRAY GRAY GRAY GRAY
330904105
Table 36, Neoprene-in-Shear Isolators, AGS 120C – 210C, Copper Fin
Mounting Location (See Footprint Drawing, page 13)
AGS
Model
M1 M2 M3 M4 M5 M6 Kit Number
120
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, BLK RP-4, BLK
125
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, BLK RP-4, BLK
330904111
130
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
135
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
140
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
145
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
160
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
330904112
165
RP-4, GRN RP-4, GRN RP-4, RED RP-4, RED RP-4, BLK RP-4, BLK 330904131
170
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED 330904112
175
RP-4, GRN RP-4, GRN RP-4, GRN RP-4, GRN RP-4, RED RP-4, RED 330904113
180
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
190
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
330904112
195
RP-4, GRN RP-4, GRN RP-4, GRN RP-4, GRN RP-4, RED RP-4, RED
210
RP-4, GRN RP-4, GRN RP-4, GRN RP-4, GRN RP-4, RED RP-4, RED
330904113
