McQuay AWS User Manual

KOMAC00607-09EN 49
Figure 13, Home Page, Main Menu Parameters and Links
View/Set Unit
Home Page
Status/Settings
>
Enter Password Set-Up
>
Continue W/O Password Temperatures
>
Date/Time/Schedules
>
Power Conservation
>
LON Setup
BACnet IP Setup
Main Menu
BACnet MSTP Setup
V
iew/Set - Unit
>
Modbus Setup
View/Set - Circuit
>
AWM Setup
Unit Status *
R
Active Setpoint *
R
Design Conditions
>
Evap Leaving Water Temp * R Alarm Limits
>
Evap Entering Water Temp * R
Unit Capacity * R
Unit Current R Menu Password
>
Softload Limit Value R
Network Limit Value R
Demand Limit Value R
V
iew/Set Circuit
>
Unit Mode * R
Control Source * R/W
Current Limit Setpoint R/W Status/Settings
>
Compressor
>
Time Until Restart
>
Scheduled Maintenance
>
Alarms
>
Time Until Restart
Compressor 1 Cycle Time Remaining * R
About This Chiller
>
Compressor 2 Cycle Time Remaining * R
Compressor 3 Cycle Time Remaining * R
Compressor 4 Cycle Time Remaining * R
A
larms
>
Alarm Active
>
Alarm Log
>
Scheduled Maintenance
Next Maintenance Month/Year * R/W
Service Support Reference * R
A
bout This Chiller
Model Numbe
r
* R
G. O. Number * R
Unit Serial Number * R
Starter Model Number(s) * R
Starter Serial Number(s) * R
Firmware Version * R
Application Version * R
Application GUID * R
HMI GUID * R
Note: Parameters with an “*” are available without entering a password.
