Physical Data
Physical Data
Unit Data
Table 1: Unit Data
Shipping Weights
Table 2: Approximate Shipping Weights - lbs (kg)*
02 03 04 06 08 10 12
Primary Coil Data
Face Area, ft
2
(cm
2
)
0.74 (685) 1.08 (1004) 1.43 (1323) 2.11 (1962) 2.46 (2281) 3.14 (2917) 3.83 (3559)
Fins/inch (cm) 12 [4.7] 12 [4.7] 12 [4.7] 12 [4.7] 12 [4.7] 12 [4.7] 12 [4.7]
Coil Connection 1/2" Nominal copper female (5/8" OD)
Coil Dimensions
2-Row
L x D x H, in (cm)
11.8 x 1.7 x 9
(30.0x4.4x22.9)
17.3 x 1.7 x 9
(43.9x4.4x22.9)
22.8 x 1.7 x 9
(57.9x4.4x22.9)
33.8 x 1.7 x 9
(85.9x4.4x22.9)
39.3x 1.7 x 9
(99.8x4.4x22.9)
50.2 x 1.7 x 9
(127.6x4.4x22.9)
61.3 x 1.7 x 9
(155.7x4.4x22.9)
3-Row
L x D x H, in (cm)
11.8 x 2.6 x 9
(30x6.6x22.9)
17.3 x 2.6 x 9
(43.9x6.6x22.9)
22.8 x 2.6 x 9
(57.9x6.6x22.9)
33.8 x 2.6 x 9
(85.9x6.6x22.9)
39.3 x 2.6 x 9
(99.8x6.6x22.9)
50.2 x 2.6 x 9
(127.6x6.6x22.9)
61.3 x 2.6 x 9
(155.7x6.6x22.9)
4-Row
L x D x H, in (cm)
11.8 x 3.5 x 9
(30.0x8.8x22.9)
17.3 x 3.5 x 9
(43.9x8.8x22.9)
22.8 x 3.5 x 9
(57.9x8.8x22.9)
33.8 x 3.5 x 9
(85.9x8.8x22.9)
39.3 x 3.5 x 9
(99.8x8.8x22.9)
50.2 x 3.5 x 9
(127.6x8.8x22.9)
61.3 x 3.5 x 9
(155.7x8.8x22.9)
Coil Volume, Gal (Liters)
2-Row 0.15 (0.6) 0.19 (0.7) 0.24 (0.9) 0.32 (1.2) 0.37 (1.4) 0.46 (1.7) 0.55 (2.1)
3-Row 0.20 (0.7) 0.26 (1.0) 0.32 (1.2) 0.45 (1.7) 0.52 (2.0) 0.64 (2.4) 0.77 (2.9)
4-Row 0.26 (1.0) 0.34 (1.3) 0.43 (1.6) 0.61 (2.3) 0.70 (2.6) 0.87 (3.3) 1.05 (4.0)
Reheat Coil Data: 1-Row, Hot Water or Steam
Face Area, ft
2
(cm
2
)
0.49 (456) 0.72 (669) 0.95 (882) 1.41 (1308) 1.64 (1521) 2.09 (1944) 2.55 (2372)
Fins/inch (cm) 12 [4.7] 12 [4.7] 12 [4.7] 12 [4.7] 12 [4.7] 12 [4.7] 12 [4.7]
Coil Connection 1/2" Nominal copper female (5/8" OD)
L x D x H, in (cm) 11.8 x 0.9 x 6
(30.0x2.2x15.2)
17.3 x 0.9 x 6
(43.9x2.2x15.2)
22.8 x 0.9 x 6
(57.9x2.2x15.2)
33.8 x 0.9 x 6
(85.9x2.2x15.2)
39.3 x 0.9 x 6
(99.8x2.2x15.2)
50.2 x 0.9 x 6
(127.6x2.2x15.2)
61.3 x 0.9 x 6
(155.7x2.2x15.2)
Volume, Gal (Liters) 0.04 (0.1) 0.05 (0.2) 0.07 (0.3) 0.10 (0.4) 0.11 (0.4) 0.14 (0.5) 0.17 (0.7)
Preheat Coil Data, 2-Row, Hot Water or Steam
Hot Water or Steam
Face Area, ft
2
(cm
2
)
0.49 (456) 0.72 (669) 0.95 (882) 1.41 (1308) 1.64 (1521) 2.09 (1944) 2.55 (2372)
Fins/inch (cm) 12 [4.7] 12 [4.7] 12 [4.7] 12 [4.7] 12 [4.7] 12 [4.7] 12 [4.7]
Coil Connection 1/2" Nominal copper female (5/8" OD)
L x D x H, in. (cm) 11.8 x 1.7 x 6
(30.0x4.4x15.2)
17.3 x1.7 x 6
(43.9x4.4x15.2)
22.8 x 1.7 x 6
(57.9x4.4x15.2)
33.8 x 1.7 x 6
(85.9x4.4x15.2)
39.3 x 1.7 x 6
(99.8x4.4x15.2)
50.2 x 1.7 x 6
(127.6x4.4x15.2)
61.3 x 1.7 x 6
(155.7x4.4x15.2)
Volume, Gal (Liters) 0.08 (0.3) 0.10 (0.4) 0.13 (0.5) 0.19 (0.7) 0.22 (0.8) 0.29 (1.1) 0.35 (1.3)
Fan/Motor Data
Fan Quantity 1 1 2 2 3 4 4
Size, Dia” x W” (cm) 6.26 x 6.3
(15.9 x 16)
7.95 x 6.3
(20 x 16)
6.26 x 6.3
(15.9 x 16)
7.95 x 6.3
(20 x 16)
6.26 x 6.3
(15.9 x 16)
6.26 x 6.3
(15.9 x 16)
7.95 x 6.3
(20 x 16)
Motor Quantity 1 1 1 1 2 2 2
Filter Data
Part Number 668332901 668332902 668332903 668332907 668332905 668332906 668332904
1” (25.4 cm) Media TA only TA only TA only TA only TA only TA only TA only
Quantity 1 1 1 1 2 2 2
L x D x H, in. (cm) 16 x 8.75 x 1
(40.6 x 22 x 2.5)
21.5 x 8.75 x 1
(54.6 x 22 x 2.5)
27 x 8.75 x 1
68.5 x 22 x 2.5
38 x 8.75 x 1
(96.5 x 22 x 2.5)
21.7 x 8.75 x 1
(56.1 x 22 x 2.5)
27.2 x 8.75 x 1
(69.0 x 22 x 2.5)
32.7 x 8.75 x 1
(83.1 x 22 x 2.5)
Unit Type
Unit Size
S02S03S04S06S08S10S12
FCVC,FCVS 84 (38) 95 (43) 108 (49) 131 (60) 152 (69) 177 (80) 202 (92)
FCVH 55 (25) 63 (29) 74 (34) 91 (41) 110 (50) 129 (59) 149 (68)
Note: *Approximate shipping weights do not include valve packages, hot water coils, electric heaters or other options.
