IM 1121 - Hideaway Unit Discharge Conversion Kit
Safety Information
Introduction
There may be instances when the airflow discharge direction
needs to be changed. The appropriate conversion kits are
available from McQuay for field installation. Contact your
McQuay Sales Represetative for details.
Procedure
Top discharge to front discharge
1 Remove the discharge duct collar from the top of the unit
by removing the screws (see Figure 1). Save all screws
for future use.
2 Remove the screws holding the fan deck to the front
block-off plate and slide the fan deck part-way out.
3 Remove the front block-off plate by removing the
mounting screws located on either side of the chassis
(see Figure 1).
4 Attach the top block-off plate to the top of the unit
replacing the discharge duct collar using the retained
screws (see Figure 2).
5 Attach the short front panel to the front of the chassis as
shown. Secure the short panel with four of the retained
screws, two on either side (see Figure 2).
Installation and Maintenance Manual IM 1121
ThinLine™ 3G Hideaway Unit
Discharge Conversion Kit
Group: Applied Air Systems
Part Number: 910118016
Date: March 2011
WARNING
The installation of this equipment shall be in accordance with
the regulations of authorities having jurisdiction and all
applicable codes. It is the responsibility of the installer to
determine and follow the applicable codes. This equipment is to
be installed only by an experienced installation company which
employs trained personnel.
WARNING
Rigorously adhere to field wiring procedures regarding proper
lockout and tagout of components.
WARNING
To avoid electrical shock, personal injury or death:
1. Installer must be qualified, experienced technician.
2. Disconnect power supply before installation to prevent
electrical shock and damage to equipment.
Table 1: Discharge Conversion Kits
Unit Size Part Number Quantity
02 910113221 1
03 910113222 1
04 910113223 1
06 910113224 1
08 910113225 1
10 910112579 1
12 910113226 1
