36 McQuay IM 1121
Figure 1: Removing the Discharge Duct Collar and Front Block-off Plate
Figure 2: Attaching the Top Block-Off Plate and Short Front Panel
Front Block-Off Plate
Discharge Duct Collar
Short Front Panel
Top Block-Off Plate
