McQuay IM 980-1 29
Model Number Description
Model Number De scription
Table 1: Model Number Description: Fields 1 - 21
1
Unit Type
•FC = fan coil
FH = cabinet unit heater
2 Product Identifier
VC = vertical cabinet, flat top
VH = vertical hideaway
VS = vertical cabinet, slope top
WC = wall-hung cabinet
3 Design Series
•1 = Design 1
4 Unit Size - nominal capacity
02 = 200 cfm
03 = 300 cfm
04 = 400 cfm
06 = 600 cfm
08 = 800 cfm
10 = 1000 cfm
12 = 1200 cfm
14 = 1400 cfm
5 Volts/Hertz/Phase
A = 115/60/1
E = 208-230/60/1
J = 265-277/60/1
6 Coil fin type
A = aluminum
7 Coil casing material
G = galvanized
8 Coil air vent
M = manual
•A = auto
9 Coil coating
Y = none
10 Not currently used
YY = none
11 Primary Coil Type
C = chilled water only
W = CW/HW 2-pipe
H = hot water only
S = steam
12 Primary Coil Rows
•2 = 2 row
•3 = 3 row
•4 = 4 row
13 Primary Coil Fins Per Inch
12 = 12 fins per inch
14 Primary Coil Connection Hand
L = left hand
R = right hand
15 Primary Coil Piping Package
F = factor installed
L = shipped loose
Y = none
16 Primary Coil Connection Type
S = sweated
T = threaded
N = none
17 Preheat Coil Type
E1 = electric single stage
W1 = 1-row water
W2 = 2-row water
S1 = 1-row steam
S2 = 2-row steam
YY = none
18 Preheat Coil Fins Per Inch
12 = 12 fins per inch
19 Preheat Coil Connection Hand
L = left hand
R = right hand
Y = none
20 Preheat Coil Piping Package
F = factor installed
L = shipped loose
Y = none
21 Preheat Coil Connection Type
S = sweated
T = threaded
N = none
Field
123456789101112131415161718192021
Code
FC VC 1 02 A A G M Y YY W 3 12 R F T YY 12 Y Y N
