Heat Pump Unit (50Hz)
MODEL MAC080CR MAC100CR
Btu/hr 76,800 92,100
kcal/hr 19,350 23,220
NOMINAL COOLING CAPACITY
Watt 22,500 27,000
Btu/hr 81,900 97,200
kcal/hr 20,640 24,510
NOMINAL HEATING CAPACITY
Watt 24,000 28,500
MATERIAL Electro-galvanised Mild Steel
FINISH Polyester Power
CASING
THICKNESS mm 1.0
HEIGHT (H) mm (in) 1260 (49.6)
WIDTH (W) mm (in) 1500 (59.1)
TOTAL
UNIT
DIMENSION
DEPTH (D) mm (in) 900 (35.4)
NET WEIGHT kg 350 360
NOISE LEVEL dB(A) 62 64
EVAPORATOR
TYPE Brazed Plate Heat Exchanger
PLATE MATERIAL Stainless Steel
HEAT EXCHANGE AREA m
2
2.26 2.78
NOMINAL WATER FLOW (COOLING/HEATING) l/s 1.08/1.14 1.31/1.39
BPHE PRESSURE DROP VS NOMINAL FLOW RATE (C/H) kPa 74/72 82/80
UNIT PRESSURE DROP VS NOMINAL FLOW RATE kPa 104 121
WATER LINE(HYDRAULIC KIT)
TYPE Horizontal Multistage End-Suction
POWER SUPPLY V/Ph/Hz 380 / 3 / 50
RUNNING CURRENT Amp 1.1 1.1
PUMP
WATER FLOW RATE ( C / H ) GPM U.S. (l/s) 17.17(1.08)/18.05(1.14) 20.70(1.31)/22.02(1.39)
INSTALLATION PIPE CONNECTION mm (in) 42 (Rc 1-1/4) 42 (Rc 1-1/4)
PIPING
HEAD (C / H) m 26/25 23.5/22.5
MATERIAL Steel EXPANSION
TANK
CAPACITY / VOLUME litres 8 8
CONDENSER COIL
TYPE
Cross Finned Tubes
MATERIAL Seamless Copper
WALL THICKNESS mm (in) 0.35 (0.014)
TUBE
OUTER DIAMETER mm (in) 9.52 (3/8)
MATERIAL Aluminium
THICKNESS mm (in) 0.127 (0.0005)
ROWS 2 2
FIN
FINS PER INCH 14 14
FACE AREA
m
2
(ft
2
) 2.5 (26.9) 2.5 (26.9)
CONDENSER FAN
TYPE/DRIVE Propeller/Direct
QUANTITY 2 2
BLADE MATERIAL Aluminium
BLADE DIAMETER mm (in) 600 (23.6) 600 (23.6)
POWER SUPPLY V/Ph/Hz 220 / 1 / 50 220 / 1 / 50
RATED RUNNING CURRENT Amp 0.9*2 0.9*2
RATED INPUT Watt 120*2 120*2
RATED OUTPUT Watt 200*2 200*2
MOTOR POLES 8 8
AIR VOLUME cmm/cfm 100*2 / 3530*2 100*2 / 3530*2
COMPRESSOR
TYPE Scroll Scroll
POWER SUPPLY V/Ph/Hz 380 / 3 / 50 380 / 3 / 50
RATED RUNNING CURRENT (COOLING) Amp 7.3*2 8.6*2
RATED RUNNING CURRENT (HEATING) Amp 7.3*2 8.6*2
RATED INPUT (COOLING) Watt 3,900*2 4,800*2
RATED INPUT (HEATING) Watt 3,900*2 4,800*2
MAXIMUM STARTING CURRENT Amp 40 48
PROTECTION DEVICES Overload Protection, Flow Switch & H/L Pressure Switch
STAGE OF CAPACITY CONTROL (%) 0-50-100
REFRIGERANT
TYPE R22
CONTROL Capillary Tube
CHARGING MASS kg 4.0*2 4.6*2
Notes:
1. All specifications are subjected to change by manufacturer without prior notice.
2. Nominal cooling values are based on entering/leaving chilled water temperature 12ºC/7ºC and air ambient temperature 35ºC.
3. Nominal heating values are based on entering/leaving hot water temperature 40ºC/45ºC and air ambient temperature 7ºC.
