Heat Pump Unit (50Hz)
MODEL MAC120CR MAC150CR
Btu/hr 112,600 129,700
kcal/hr 28,380 32,670
NOMINAL COOLING CAPACITY
Watt 33,000 38,000
Btu/hr 119,400 136,500
kcal/hr 30,090 34,390
NOMINAL HEATING CAPACITY
Watt 35,000 40,000
MATERIAL Electro-galvanised Mild Steel
FINISH Polyester Power
CASING
THICKNESS mm 1
HEIGHT (H) mm (in) 1260 (49.6)
WIDTH (W) mm (in) 1800 (70.9)
TOTAL UNIT DIMENSION
DEPTH (D) mm (in) 1150 (45.3)
NET WEIGHT kg 480 560
NOISE LEVEL dB(A) 67 70
EVAPORATOR
TYPE Brazed Plate Heat Exchanger
PLATE MATERIAL Stainless Steel
HEAT EXCHANGE AREA m
2
3.0 3.6
NOMINAL WATER FLOW (COOLING/HEATING) l/s 1.67/1.78 2.0/2.11
BPHE PRESSURE DROP VS NOMINAL FLOW RATE (C/H) kPa 76/74 75/73
UNIT PRESSURE DROP VS NOMINAL FLOW RATE kPa 138 155
WATER LINE(HYDRAULIC KIT)
TYPE Horizontal Multistage End-Suction
POWER SUPPLY V/Ph/Hz 380 / 3 / 50
RUNNING CURRENT Amp 2.5 2.5
PUMP
WATER FLOW RATE ( C / H ) GPM U.S. (l/s) 26.42(1.67)/28.18(1.78) 31.70(2.0)/33.47(2.11)
INSTALLATION PIPE
CONNECTION
mm (in) 42 (Rc 1-1/4) 42 (Rc 1-1/4)
PIPING
HEAD (C / H) m 31/29 28/26
MATERIAL Steel
EXPANSION
TANK
CAPACITY / VOLUME litres 8 8
CONDENSER COIL
TYPE Cross Finned Tubes
MATERIAL Seamless Copper
WALL THICKNESS mm (in) 0.35 (0.014)
TUBE
OUTER DIAMETER mm (in) 9.52 (3/8)
MATERIAL Aluminium
THICKNESS mm (in) 0.127 (0.0005)
ROWS 2 2
FIN
FINS PER INCH 14 14
FACE AREA m
2
(ft
2
) 2.5 (26.9) 2.5 (26.9)
CONDENSER FAN
TYPE/DRIVE Propeller/Direct
QUANTITY 2 2
BLADE MATERIAL
BLADE DIAMETER mm (in) 660 (26) 660 (26)
POWER SUPPLY V/Ph/Hz 380 / 3 / 50
RATED RUNNING CURRENT Amp 0.86*2 4.5*2
RATED INPUT Watt 200*2 450*2
RATED OUTPUT Watt 470*2 820*2
MOTOR POLES 8 6
AIR VOLUME cmm/cfm 142*2 / 5000*2 142*2 / 5000*2
COMPRESSOR
TYPE Scroll Scroll
POWER SUPPLY V/Ph/Hz 380 / 3 / 50 380 / 3 / 50
RATED RUNNING CURRENT (COOLING) Amp 10.3*2 11.5*2
RATED RUNNING CURRENT (HEATING) Amp 10.3*2 11.5*2
RATED INPUT (COOLING) Watt 5,300*2 6,240*2
RATED INPUT (HEATING) Watt 5,300*2 6,240*2
MAXIMUM STARTING CURRENT Amp 55 62
PROTECTION DEVICES Overload Protection, Flow Switch & H/L Pressure Switch
STAGE OF CAPACITY CONTROL (%) 0-50-100
REFRIGERANT
TYPE R22
CONTROL Capillary Tube
CHARGING MASS kg 7.5*2 6.8*2
Notes:
1. All specifications are subjected to change by manufacturer without prior notice.
2. Nominal cooling values are based on entering/leaving chilled water temperature 12ºC/7ºC and air ambient temperature 35ºC.
3. Nominal heating values are based on entering/leaving hot water temperature 40ºC/45ºC and air ambient temperature 7ºC.
