McQuay MAC040A User Manual

Cooling In Heat Pump Version
AMBIENT TEMPERATURE ON CONDENSER (°C)
19 28 32 35 40 42 46
MODEL
LEAVING WATER
TEMPERATURE (°C)
COOL
CAP.
kW
POWER
INPUT
kW
COOL
CAP.
kW
POWER
INPUT
kW
COOL
CAP.
kW
POWER
INPUT
kW
COOL
CAP.
kW
POWER
INPUT
kW
COOL
CAP.
kW
POWER
INPUT
kW
COOL
CAP.
kW
POWER
INPUT
kW
COOL
CAP.
kW
POWER
INPUT
kW
5 9.12 2.42 8.63 2.58 8.50 2.72 8.38 3.07 8.07 3.31 7.95 3.50 7.70 3.71
6 9.49 2.46 8.89 2.60 8.57 2.90 8.50 3.24 8.18 3.47 8.06 3.69 7.83 3.91
7 9.88 2.54 9.15 2.64 8.70 3.03 8.53 3.40 8.29 3.65 8.20 3.83 7.98 3.99
8 10.17 2.59 9.41 2.69 8.83 3.16 8.71 3.54 8.36 3.80 8.25 3.95 8.11 4.12
9 10.69 2.63 9.75 2.71 9.16 3.25 8.88 3.71 8.48 3.88 8.37 4.08 8.23 4.27
M4AC040AR
M4AC040ARE
10 11.19 2.71 10.39 2.75 9.72 3.39 9.15 3.86 8.57 4.04 8.43 4.23 8.31 4.41
5 10.70 3.96 10.32 4.19 9.73 4.40 8.95 4.53 8.12 4.67 7.82 4.71 7.76 4.84
6 12.35 4.03 11.85 4.25 11.08 4.44 10.19 4.61 9.06 4.75 8.63 4.78 8.32 5.02
7 13.85 4.12 13.32 4.30 12.20 4.48 11.37 4.64 10.03 4.91 9.45 4.98 8.89 5.11
8 14.64 4.19 13.99 4.35 13.68 4.53 12.60 4.69 11.31 5.03 10.21 5.13 9.58 5.24
9 15.68 4.28 14.86 4.41 14.61 4.58 13.52 4.72 12.10 5.16 10.83 5.22 9.90 5.39
M4AC050AR
M4AC050ARE
10 16.71 4.31 15.84 4.43 15.54 4.61 14.60 4.76 13.32 5.30 11.96 5.34 10.72 5.49
5 12.62 4.06 11.85 4.16 11.72 4.26 11.57 4.43 11.47 4.91 11.34 5.05 10.87 5.35
6 13.63 4.10 12.78 4.31 12.63 4.46 12.46 4.62 12.37 5.10 12.26 5.32 11.57 5.57
7 14.78 4.15 13.94 4.41 13.76 4.65 13.64 4.78 13.43 5.30 13.37 5.50 12.36 5.78
8 15.88 4.24 15.05 4.69 14.91 4.88 14.79 5.06 14.58 5.49 14.26 5.67 13.48 6.00
9 17.01 4.32 15.96 4.89 15.88 5.15 15.79 5.37 15.68 5.69 15.30 5.91 14.38 6.18
M4AC058AR
M4AC058ARE
10 17.93 4.41 17.01 5.11 16.87 5.38 16.64 5.57 16.48 5.97 16.14 6.14 15.28 6.33
