Wiring Diagrams
Model : MAC040 / 050 A, M4AC040 / 050A (Cooling Only)
Model : MAC058A , M4AC058A (Cooling Only)
SYMBOL DESCRIPTION
PCB PRINTED CIRCUIT BOARD
FS FLOW SWITCH
SW SWITCH
AHTR ANTIFREEZE HEATER WIRE
FM FAN MOTOR
COMP COMPRESSOR
EARTH
SYMBOL DESCRIPTION
PCB PRINTED CIRCUIT BOARD
FS FLOW SWITCH
SW SWITCH
AHTR ANTIFREEZE HEATER WIRE
FM FAN MOTOR
COMP COMPRESSOR
EARTH
35
