Heat Pump (Schematic Diagram)
(MAC075 ~ 125BR)
17
1. SCROLL COMPRESSOR 9. SUCTION ACCUMULATOR
2. 4 WAY VALVE 10. BPHE
3. HEAT EXCHANGER 11. CHILLER WATER OUT
4. FAN MOTOR 12. CHILLER WATER IN
5. FILTER DRIER 13. PUMP
6. CHECK VALVE 14. WATER STORAGE TANK
7. CAP TUBE 15. EXPANSION TANK
8. DIFFERENTIAL PRESSURE REGULATOR 16. AUTO- AIRVENT
17. FLOW SWITCH
52
