©2009McQuay
12
Model: MAC090D4
UNIT: mm
Model
A B C D E F G H
MAC090D4 900 990 180 215 285 271 Rc1-1/2 Rc1-1/2
MAC120D4 1200 1290 180 215 286 267 Rc1-1/2 Rc1-1/2
FE
C
Outlet G
D
Inlet H
4-14
×
20 Fixing Hole Zoom
265
1840
B 8
1575
B
A
840
45
845
877
Fixing Hole 4-14
×
20
16
