©2009McQuay
27
Schematic Diagram
MAC060D4 (MAC090/120D4 is two compressors paralleled)
6.Difference Pressure Switch
3.Throttle Device
7.Accumulator
1.Compressor
4.Bphe
LEGEND
7
1
5.Water Pump
2.Heat Exchanger Fan
Refrigerant Fow Direction
Chilled Water In
Chilled Water Out
6
5
4
2
3
