COOLING CAPACITY
(Btu/h) 3 Rows Coil
Entering Air Temperature ºF (ºC)
DB = 75.2(24) DB = 77(25) DB = 78.8(26) DB = 80(26.7) DB = 80.6(27) DB = 80.6(27) DB = 82.4(28)
WB = 62.6(17) WB = 64.4(18) WB = 66.2(19) WB = 67(19.4) WB = 67.1(19.5) WB = 68(20) WB = 69.8(21)
Model
Entering
Water
Temp.
ºF (ºC)
Water Flow
l/min
W.P.D
kPa
TH SH TH SH TH SH TH SH TH SH TH SH TH SH
6 5.9 8945 6935 9730 7130 10570 7330 10970 7660 11035 7710 11435 7525 12270 7685
8 9.3 9850 7315 10785 7570 11750 7810 12200 8150 12265 8205 12740 8040 13755 8265
10 13.2 10535 7610 11550 7890 12620 8170 13100 8530 13180 8585 13695 8430 14840 8695
MCW300C 41 (5)
12 17.6 11055 7840 12150 8150 13250 8440 13760 8810 13845 8865 14395 8725 15575 9000
6 5.9 8260 6650 9100 6875 9935 7080 10340 7410 10400 7460 10750 7260 11625 7440
8 9.3 9140 7020 10035 7260 10995 7505 11440 7850 11505 7900 11975 7740 12985 7965
10 13.2 9750 7270 10760 7555 11795 7830 12280 8180 12350 8240 12890 8105 13995 8360
MCW300C 42.8 (6)
12 17.6 10215 7475 11305 7785 12400 8080 12910 8440 12985 8500 13560 8375 14730 8655
6 5.9 7590 6380 8400 6595 9260 6820 9630 7140 9685 7185 10105 7015 10970 7195
8 9.3 8395 6705 9315 6960 10225 7195 10700 7550 10775 7610 11200 7435 12205 7665
10 13.2 8950 6940 9950 7225 10980 7500 11460 7850 11535 7910 12045 7765 13145 8020
MCW300C
44.6 (7)
12 17.6 9385 7120 10445 7425 11540 7720 12040 8090 12120 8145 12685 8020 13880 8310
6 5.9 6705 6230 7690 6325 8540 6540 8930 6870 8995 6925 9380 6740 10285 6950
8 9.3 7675 6415 8585 6670 9490 6905 9930 7250 10000 7305 10455 7145 11410 7365
10 13.2 8170 6615 9135 6895 10160 7170 10630 7520 10705 7580 11215 7440 12300 7700
MCW300C 46.4 (8)
12 17.6 8545 6770 9590 7080 10675 7375 11180 7740 11255 7800 11800 7665 13975 7960
6 5.9 6055 5970 7025 6065 7845 6280 8230 6610 8295 6660 8680 6485 9535 6675
8 9.3 6900 6110 7825 6375 8755 6620 9190 6970 9260 7025 9675 6855 10660 7085
10 13.2 7380 6295 8340 6575 9325 6840 9820 7210 9895 7270 10370 7115 11450 7375
MCW300C 48.2 (9)
12 17.6 7710 6430 8735 6730 9810 7030 10300 7400 10380 7455 10920 7325 12065 7610
6 5.9 5650 5570 6055 5980 7145 6020 7540 6350 7600 6405 7975 6225 8785 6410
8 9.3 5980 5895 7030 6065 7955 6320 8390 6670 8455 6720 8925 6575 9895 6810
10 13.2 6565 5975 7535 6260 8515 6535 8980 6890 9055 6945 9550 6800 10590 7055
MCW300C 50 (10)
12 17.6 6865 6095 7880 6395 8925 6685 9420 7060 9495 7115 10025 6985 11165 7270
Page 12
W.P.D: Water Pressure Drop Dry Bulb ** WB: Wet Bulb
Fan speed correction factor
TH: Total Heat SH: Sensible Heat
Medium Low
MODEL
Total Sensible Total Sensible
MCW300C 0.84 0.86 0.70 0.66
Fan Speed: High 1 Btu = 0.2928104 W
