McQuay MCW 200 C User Manual

COOLING CAPACITY (Btu/h) 3 Rows Coil
Entering Air Temperature ºF (ºC)
DB = 75.2(24) DB = 77(25) DB = 78.8(26) DB = 80(26.7) DB = 80.6(27) DB = 80.6(27) DB = 82.4(28)
WB = 62.6(17) WB = 64.4(18) WB = 66.2(19) WB = 67(19.4) WB = 67.1(19.5) WB = 68(20) WB = 69.8(21)
Model
Entering
Water
Temp. ºF
(ºC)
Water Flow
l/min
W.P.D
kPa
TH SH TH SH TH SH TH SH TH SH TH SH TH SH
7 7.3 11195 8670 12180 8910 13230 9165 13450 9340 13810 9630 14310 9400 15360 9605
10 13.8 12615 9265 13820 9590 15055 9900 15310 10090 15725 10405 16335 10205 17680 10510 13 22.0 13605 9690 14915 10055 16300 10425 16580 10620 17030 10950 17700 10770 19140 11100
MCW400C 41 (5)
16 31.8 14270 9985 15660 10380 17100 10765 17390 10970 17865 11305 18585 11145 20125 11510
7 7.3 10345 8310 11395 8590 12435 8845 12650 9020 13015 9320 13450 9065 14545 9300
10 13.8 11670 8860 12865 9190 14095 9505 14340 9700 14755 10010 15360 9815 16665 10105 13 22.0 12565 9245 13875 9610 15245 9980 15520 10180 15970 10505 16675 10345 18105 10685
MCW400C 42.8 (6)
16 31.8 13200 9515 14615 9925 16040 10310 16330 10520 16800 10855 17515 10695 19040 11060
7 7.3 9505 7975 10515 8245 11595 8515 11800 8690 12125 8980 12650 8765 13730 8995
10 13.8 10745 8475 11895 8795 13120 9115 13370 9310 13770 9620 14375 9425 15665 9720 13 22.0 11545 8810 12845 9180 14180 9545 14450 9740 14895 10070 15590 9905 17010 10250
MCW400C 44.6 (7)
16 31.8 12120 9050 13510 9460 14935 9850 15220 10050 15685 10390 16430 10245 17945 10610
7 7.3 8655 7635 9630 7895 10695 8170 10910 8350 11265 8650 11740 8425 12870 8675
10 13.8 9820 8100 10960 8415 12165 8745 12410 8930 12820 9245 13375 9035 14655 9335 13 22.0 10510 8380 11795 8750 13125 9115 13390 9310 13830 9640 14495 9470 15910 9815
MCW400C 46.4 (8)
16 31.8 11035 8600 12400 9000 13805 9395 14090 9600 14565 9930 15290 9785 16825 10170
7 7.3 7570 7460 8800 7575 9780 7830 10010 8020 10390 8320 10830 8090 11935 8340
10 13.8 8855 7715 10015 8050 11175 8355 11440 8550 11865 8875 12410 8670 13635 8960 13 22.0 9490 7965 10735 8330 12055 8695 12320 8890 12760 9220 13410 9050 14815 9395
MCW400C 48.2 (9)
16 31.8 9935 8150 11290 8550 12690 8945 12970 9150 13435 9480 14135 9330 15660 9715
7 7.3 7070 6965 7575 7480 8950 7525 9160 7700 9515 8000 9980 7780 11000 8010
10 13.8 7565 7455 9005 7660 10220 7995 10470 8190 10870 8500 11435 8310 12655 8600 13 22.0 8450 7555 9615 7895 10965 8275 11240 8480 11695 8815 12315 8635 13705 8985
MCW400C 50 (10)
16 31.8 8840 7710 10160 8105 11550 8505 11830 8710 12290 9040 12985 8890 14470 9270
Page 13
W.P.D: Water Pressure Drop Dry Bulb ** WB: Wet Bulb Fan speed correction factor TH: Total Heat SH: Sensible Heat
Medium Low
MODEL
Total Sensible Total Sensible
MCW400C 0.88 0.86 0.76 0.72
Fan Speed: High 1 Btu = 0.2928104 W
