12
Electrical wiring connection must be done according to the following wiring diagram. The unit must be GROUNDED
to the earth system of the building. All eld wiring must be installed in accordance with the national wiring regulation
and Fire Department regulation.
Wiring Diagrams
Note:
For MCWD series, (H. M. L.) are connected to (SHF. HF. MF.) respectively.
MODEL: MCW 200~1400
POWER
SOURCE
ORANGE
DRAWING NO.:M08024067082
N
L
MF
LF
SHF
HF
L
M
BROWN
H
YELLOW
FAN
BLACK
FAN SPEED
SWITCH
NOTE:
MOTOR
1
BLACK
FAN MOTOR
CAPACITOR
MOTOR
CAPACITOR
2
BLACK
FAN MOTOR
BLACK
FAN
RED
RED
YELLOW
BROWN
ORANGE
BLUE
BLUE
HF: HIGH SPEED
MF: MEDIUM SPEED
LF: LOW SPEED
SHF: SUPER HIGH SPEED
FIELD WIRING
FAN MOTOR2 APPLY TO 800~1400 UNITS
50~60Pa UNITS: (H,M,L) CONNECT TO (HF,MF,LF)
70~80Pa UNITS: (H,M,L) CONNECT TO (SHF,HF,MF)
To Next Page
