Exploded-view & Part List
8.FAN
6.FILTER
7.MOTOR
2.FANDECK
4.PLENUM
1.TOP PLATE
3.DRAIN GUIDE PLATE
5.COIL
9.DRAIN PAN
10. HEDER OUTLET
11. HEADER NLET
