McQuay MCW300D User Manual

7
Cooling Capacity ( The table below is an example)
Performance Data
NOTES:
1. COOLING CAPACITY AND HEATING CAPAITY ARE GIVEN WITH ESP OF 75PA AT MEDIUM SPEED.
2. COOLING CAPACITY IS BASED ON 5.5°C ENTERING WATER TEMPERATURE AND 14.5°C LEAVING WATER TEM-
PERATURE.
ON COIL CONDITIONS ARE SHOWN IN THE TABLES
3. HEATING CAPACITY IS BASED ON 21°C ENTERING AIR TEMPERATURE(DB) AND 60 °C ENTERING WATER TEM-
PERATURE WITH THE SAME AMOUNT OF WATER FLOW VOLUME AS COOLING
4. CAPACITY UNDER DIFFERENT ENTERING WATER TEMPERATURE AND SPEED CAN BE DERIVED BY SELECT
SOFTWARE.
Model
ESP
Entering air
Temperature(°C)
Water
Temperature(°C)
Cooling Capacity (kw) Water ow
Water
Pressure Drop
(Pa) DB WB In Out Total Sensible m
3
/h kPa
MCW200D 75 24.0 17.9 5.5 14.5
1.5
1.0.
0.167 3.5
MCW300D 75 24.0 17.9 5.5 14.5
2.7 1.8
0.270 8.0
MCW400D 75 24.0 17.9 5.5 14.5
3.4 2.4
0.344 15.8
MCW500D 75 24.0 17.9 5.5 14.5
3.8 2.7
0.389 7.2
MCW600D 75 24.0 17.9 5.5 14.5
5.0 3.7
0.482 11.4
MCW800D 75 24.0 17.9 5.5 14.5
6.2 4.6
0.618 10.0
MCW900D 75 24.0 17.9 5.5 14.5
6.9 5.0
0.685 12.7
MCW1000D 75 24.0 17.9 5.5 14.5
8.3 6.2
0.825 21.0
MCW1200D 75 24.0 17.9 5.5 14.5
8.8 7.1
0.899 12.9
MCW1400D 75 24.0 17.9 5.5 14.5
10.0 7.8
1.031 18.4
Model
ESP
Entering air
Temperature(°C)
Water
Temperature(°C)
Cooling Capacity (kw) Water ow
Water
Pressure Drop
(Pa) DB WB In Out Total Sensible m
3
/h kPa
MCW200D 75 27.0 19.5 5.5 14.5
2.1 1.3
0.223 5.7
MCW300D 75 27.0 19.5 5.5 14.5
3.4 2.2
0.341 12.0
MCW400D 75 27.0 19.5 5.5 14.5
4.4 2.9
0.439 24.6
MCW500D 75 27.0 19.5 5.5 14.5
5.0 3.4
0.499 11.1
MCW600D 75 27.0 19.5 5.5 14.5
6.3 4.5
0.632 18.2
MCW800D 75 27.0 19.5 5.5 14.5
8.0 5.7
0.803 15.8
MCW900D 75 27.0 19.5 5.5 14.5
8.9 6.2
0.889 19.9
MCW1000D 75 27.0 19.5 5.5 14.5
10.8 7.7
1.067 29.0
MCW1200D 75 27.0 19.5 5.5 14.5
11.7 8.9
1.223 22.2
MCW1400D 75 27.0 19.5 5.5 14.5
13.1 9.7
1.368 30.3
