McQuay MCW300D User Manual

5
COMPONENTS DATA
MODEL
200D 300D 400D 500D 600D 800D 900D 1000D 1200D 1400D
FAN
TYPE CENTRIFUGAL (BLADE: FORWARD-CURVED)
QUANTITY 1 2 3 4 3
MATERIAL GALVANIZED STEEL
DRIVE DIRECT DRIVE
DIAMETER
mm 160 200
in 6.299 7.875
LENGTH
mm 200 160 200 160 190
in 7.874 6.299 7.874 6.299 7.480
MOTOR
TYPE Split-capacitoR motoR with ball beaRing
NUMBER OF MOTORS 1 2
POWER SUPPLY 220-240V/1/50
IP/INSULATION CLASS IP20/Class B
COIL
TYPE Seamless copper tube mechanically bonded to congurated aluminum n
TESTING PRESSURE Pressure test:3.3MPa for 1 minute; Leakage test:1.6MPa for 5 minutes
TUBE
MATERIAL COPPER
DIAMETER
mm 9.52
in 3/8
THICKNESS
mm 0.3
in 0.012
FIN
MATERIAL ALUMINIUM
THICKNESS
mm 0.11
in 0.0043
FACE AREA
m
2
0.1 0.14 0.16 0.18 0.20 0.25 0.27 0.29 0.25 0.29
ft
2
1.06 1.54 1.71 1.93 2.15 2.70 2.91 3.13 2.70 3.13
ROW 4
FIN PER INCH 11
AIR FILTER
(OPTIONAL)
SIZE
LENGTH
mm 502 722 802 902 1002 1252 1352 1452 1252 1452
in 19.76 28.43 31.57 35.51 39.45 49.29 53.23 57.17 49.29 57.17
WIDTH
mm 244 244 244 244 244 244 244 244 244 244
in 9.61 9.61 9.61 9.61 9.61 9.61 9.61 9.61 11.34 11.34
THICKNESS
mm 25 25 25 25 25 25 25 25 25 25
in 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98
