16 OM-121
Table 4. Status Menus
Menu Item
No. Name Name Range SWITCH Key Destination
Menu Item
1 RMC Status Schedule #1=____ Occ 10. Schedule #1 Sun
Unocc
Schedule #2=____ Occ 11. Schedule #2 Sun
Unocc
Schedule #3=____ Occ 12. Schedule #3 Sun
Unocc
Schedule #4=____ Occ 13. Schedule #4 Sun
Unocc
2 Control Temp
Group #1=____ °F
(Same as CT sensor) 5. Group #1 Cntl Temp=
Group #2=____ °F
(Same as CT sensor) 6. Group #2 Cntl Temp=
Group #3=____ °F
(Same as CT sensor) 7. Group #3 Cntl Temp=
Group #4=____ °F
(Same as CT sensor) 8. Group #4 Cntl Temp=
3 Static Press
Group #1=____ "WC
0.00 – 4.00"WC 5. Group #1 Press Spt=
Group #2=____ "WC
0.00 – 4.00"WC 6. Group #2 Press Spt=
Group #3=____ "WC
0.00 – 4.00"WC 7. Group #3 Press Spt=
Group #4=____ "WC
0.00 – 4.00"WC 8. Group #4 Press Spt=
Control Menus
Table 4 lists all possible menus, items, and adjustable fields in the Control category. The table’s
range column lists all possible values for each adjustable field. Following are brief descriptions of
the Control category menus.
Group Assignment
Menu 4, “Group Assign,” allows you to assign units to the RMC Panel’s four multiple-unit control
groups. (A multiple-unit control group is a set of two to eight units that operate as though they were
one large unit.) If the RMC Panel is being used for remote monitoring or scheduling only, all
parameters in this menu should be set to “NA.” For more information, see the “Multiple-Unit
Control Features” section in the “Description of Operation” portion of this manual.
Group #1 Setup
Menu 5, “Group #1,” contains parameters that are used to set up the first multiple-unit control
group. Two to eight units can be assigned to this group (see “Group Assignment” above). If the
RMC Panel is being used for remote monitoring or scheduling only, no parameters in this menu
need to be set. For more information, see the “Multiple-Unit Control Features” section in the
“Description of Operation” portion of this manual.
Group #2 Setup
Menu 6, “Group #2,” contains parameters that are used to set up the second multiple-unit control
group. Menu 6 is similar to menu 5; see “Group #1 Setup” above for more information.
Group #3 Setup
Menu 7, “Group #3,” contains parameters that are used to set up the third multiple-unit control
group. Menu 7 is similar to menu 5; see “Group #1 Setup” above for more information.
