McQuay MicroTech RMC-E01A - Table 5. Control Menus

18 OM-121
Table 4. Control Menus
Menu Item
No. Name Name Field Range SWITCH Key Destination
(Default Shown) No. Menu Item
4 Group Assign
Unit #1 Group=1
1 NA – –
1 – 4
Unit #2 Group=1
1 NA – –
1 – 4
Unit #3 Group=NA
1 NA – –
1 – 4
Unit #4 Group=NA
1 NA – –
1 – 4
Unit #5 Group=NA
1 NA – –
1 – 4
Unit #6 Group=NA
1 NA – –
1 – 4
Unit #7 Group=NA
1 NA – –
1 – 4
Unit #8 Group=NA
1 NA – –
1 – 4
5 Group #1
Cntl Temp=Return
1 Return 2. Control Temp Group #1=
Space
Temp Calc=Min
1 Min 2. Control Temp Group #1=
Max
Avg
Press Calc=Min
1 Min 3. Static Press Group #1=
Max
Avg
Press Spt=1.50"WC
1 0.20 – 4.00"WC 3. Static Press Group #1=
Speed/Vane=____ %
– 0 – 100% – –
Dead band=0.08"WC
1 0.00 – 0.50"WC – –
Mod Limit=0.40"WC
1 0.02 – 2.00"WC – –
Wait Time=60 Sec
1 20 Sec – 10 Min – –
Max Step=4 %
1 1 – 100% – –
6 Group #2
Cntl Temp=Return
1 Return 2. Control Temp Group #2=
Space
Temp Calc=Min
1 Min 2. Control Temp Group #2=
Max
Avg
Press Calc=Min
1 Min 3. Static Press Group #2=
Max
Avg
Press Spt=1.50"WC
1 0.20 – 4.00"WC 3. Static Press Group #2=
Speed/Vane=____ %
– 0 – 100% – –
Dead band=0.08"WC
1 0.00 – 0.50"WC – –
Mod Limit=0.40"WC
1 0.02 – 2.00"WC – –
Wait Time=60 Sec
1 20 Sec – 10 Min – –
Max Step=4 %
1 1 – 100% – –
7 Group #3
Cntl Temp=Return
1 Return 2. Control Temp Group #3=
Space
Temp Calc=Min
1 Min 2. Control Temp Group #3=
Max
Avg
Press Calc=Min
1 Min 3. Static Press Group #3=
Max
Avg
Press Spt=1.50"WC
1 0.20 – 4.00"WC 3. Static Press Group #3=
Speed/Vane=____ %
– 0 – 100% – –
Dead band=0.08"WC
1 0.00 – 0.50"WC – –
Mod Limit=0.40"WC
1 0.02 – 2.00"WC – –
Wait Time=60 Sec
1 20 Sec – 10 Min – –
Max Step=4 %
1 1 – 100% – –
