McQuay RDS 802C User Manual

16 McQuay IM 987
Mechanical Installation
Figure 16: Overhead Clearance
Figure 17: Side Discharge
24" (610 mm)
Maximum
2" (51 mm)
Minumum
Top of Unit
to Overhead
Obstruction
24" (610 mm)
Maximum
Overhead
Canopy
9" (229 mm)
Minumum to Flue Box
Typical All Sides
Flue Box
Side Discharge Opening
(Access in Ductwork
Must be Removed)
NOTICE
On units with side discharge, access to plenum-mounted
components becomes difficult once ductwork is installed.
Installer must provide access in the ductwork for plenum
mounted controls
