McQuay IM 937 13
Physical Data
Supply fan motors, continued
3 hp TEFC 72—————————— —
5 hp TEFC 85—————————— —
7.5 hp TEFC 140140————————— —
10 hp TEFC 170170170170——————— —
15 hp TEFC —235235235235235————— —
20 hp TEFC — — 300 300 300 300 300 300 300 — — —
25 hp TEFC — — — — 330 330 330 330 330 330 — —
30 hp TEFC — — — — — 390 390 390 390 390 390 390
40 hp TEFC ——————510510510510510510
50 hp TEFC —————————570570570
60 hp TEFC ——————————850850
Compressor/condenser assembly
Water weight
(4) 6 hp 43 777 777 777 777 777 777 777 777 777 777 777 777
(4) 7 hp 57 786 786 786 786 786 786 786 786 786 786 786 786
(4) 8 hp 66 1215 1215 1215 1215 1215 1215 1215 1215 1215 1215 1215 1215
(4) 9 hp 74 1272 1272 1272 1272 1272 1272 1272 1272 1272 1272 1272 1272
(3) 6 hp, (1) 10 hp 57 843 843 843 843 843 843 843 843 843 843 843 843
(2) 6 hp, (2) 10 hp 66 974 974 974 974 974 974 974 974 974 974 974 974
(1) 6 hp, (3) 10 hp 74 1115 1115 1115 1115 1115 1115 1115 1115 1115 1115 1115 1115
(4) 10 hp 95 1287 1287 1287 1287 1287 1287 1287 1287 1287 1287 1287 1287
(2) 10 hp, (2) 13 hp 106 1376 1376 1376 1376 1376 1376 1376 1376 1376 1376 1376 1376
(4) 13 hp 118 1464 1464 1464 1464 1464 1464 1464 1464 1464 1464 1464 1464
(2) 13 hp, (2) 15 hp 129 1575 1575 1575 1575 1575 1575 1575 1575 1575 1575 1575 1575
(4) 15 hp 141 1684 1684 1684 1684 1684 1684 1684 1684 1684 1684 1684 1684
(2) 15 hp, (2) 20 hp 152 1982 1982 1982 1982 1982 1982 1982 1982 1982 1982 1982 1982
(4) 20 hp 190 1970 1970 1970 1970 1970 1970 1970 1970 1970 1970 1970 1970
(6) 13 hp 167 2010 2010 2010 2010 2010 2010 2010 2010 2010 2010 2010 2010
(3) 13 hp, (3) 15 hp 178 2135 2135 2135 2135 2135 2135 2135 2135 2135 2135 2135 2135
(6) 15 hp 188 2260 2260 2260 2260 2260 2260 2260 2260 2260 2260 2260 2260
(3) 15 hp, (3) 20 hp 209 2419 2419 2419 2419 2419 2419 2419 2419 2419 2419 2419 2419
(6) 20 hp 229 2579 2579 2579 2579 2579 2579 2579 2579 2579 2579 2579 2579
Discharge plenum
23" high 551551551616616—————— —
29" high 636 636 636 711 711 862 862 862 922 1003 1064 1064
35" high 719 719 719 804 804 975 975 975 1042 1134 1203 1203
41" high 805 805 805 899 899 1090 1090 1090 1166 1269 1346 1346
a. Base weight includes supply fan without motor.
b. Water economizer weight includes valves and piping.
c. The values in this table do not include water weight.
d. Hot water coil weight includes valve and piping.
Table 6: Unit and Component Weight (lbs) (continued)
Unit weights
Unit size
018 023 028 035 040 045 055 065 070 080 095 105
