12 McQuay IM 937
Physical Data
Unit Weights
Table 6: Unit and Component Weight (lbs)
Unit weights
Unit size
018 023 028 035 040 045 055 065 070 080 095 105
Basic configuration
SWP basic unit
a
2226 2313 2318 2638 2643 3110 3279 3406 3734 4021 4246 4766
Filters
4" 30% or 65% efficiency 38 38 38 55 55 66 66 79 87 96 104 112
Evaporator coil
Heaviest coil 250 294 321 417 468 506 577 642 693 755 819 926
Water economizer coil
b
c
4 row, 12 fpi 306 338 357 458 493 520 598 648 678 723 820 927
Water weight 51 66 75 94 111 119 150 168 187 203 218 281
Hot water coil
d
c
1 row, 12 fpi 71 97 114 130 158 160 170 200 328 337 345 371
Water weight 16 20 23 28 32 37 41 49 55 59 62 62
Electric heat
34 kW 2020202020—————— —
68 kW — — — — — 40 40 40 40 40 40 40
Supply fan motors
3 hp ODP 71—————————— —
5 hp ODP 82—————————— —
7.5 hp ODP 124124————————— —
10 hp ODP 144144144144——————— —
15 hp ODP —185185185185185————— —
20 hp ODP — — 214 214 214 214 214 214 214 — — —
25 hp ODP — — — — 266 266 266 266 266 266 — —
30 hp ODP — — — — — 310 310 310 310 310 310 310
40 hp ODP ——————404404404404404404
50 hp ODP —————————452452452
60 hp ODP ——————————620620
a. Base weight includes supply fan without motor.
b. Water economizer weight includes valves and piping.
c. The values in this table do not include water weight.
d. Hot water coil weight includes valve and piping.
