Product Manual WHR-2 19
Performance Data
EW Water-Cooled
Table 5, WHR 017EW - WHR 060EW, 60 Hz, IP Units
Entering Condenser Water Temperature (10°F Delta T.)
70°F 80°F 85°F 95°F 105°F
Cap. PWR Cap. PWR Cap. PWR Cap. PWR Cap. PWR
WHR
SIZE
LWT
(°F)
Tons kWi
EER
Tons kWi
EER
Tons kWi
EER
Tons kWi
EER
Tons kWi
EER
40.0 17.8 11.7 17.1 16.9 13.1 14.7 16.5 13.7 13.7 15.6 15.0 11.8 14.6 16.3 10.2
42.0 18.4 11.8 17.7 17.6 13.1 15.1 17.1 13.8 14.1 16.2 15.2 12.1 15.1 16.5 10.4
017EW 44.0 19.1 11.8 18.3 18.2 13.2 15.6 17.7 13.9 14.4 16.7 15.4 12.4 15.7 16.7 10.7
46.0 19.8 11.9 18.7 18.9 13.3 16.0 18.3 14.0 14.8 17.3 15.5 12.6 16.3 17.0 10.9
48.0 20.4 11.9 19.4 19.5 13.3 16.6 19.0 14.1 15.3 18.0 15.6 13.1 16.9 17.1 11.3
50.0 21.2 12.0 19.9 20.1 13.5 17.0 19.6 14.2 15.7 18.6 15.8 13.4 18.1 17.4 11.7
40.0 21.8 15.5 16.1 20.7 17.3 13.8 20.2 18.2 12.8 19.1 19.9 11.1 17.9 21.6 9.6
42.0 22.6 15.6 16.6 21.5 17.4 14.2 20.9 18.3 13.2 19.8 20.1 11.3 18.6 21.8 9.8
020EW 44.0 23.4 15.7 17.1 22.3 17.5 14.6 21.7 18.4 13.5 20.5 20.3 11.6 19.3 22.1 10.1
46.0 24.3 15.7 17.6 23.1 17.6 15.0 22.5 18.6 13.9 21.2 20.5 11.9 20.0 22.4 10.3
48.0 25.1 15.8 18.2 23.9 17.7 15.5 23.3 18.7 14.3 22.0 20.7 12.3 20.7 22.6 10.6
50.0 26.0 15.8 18.7 24.7 17.8 15.9 24.1 18.8 14.7 22.8 20.9 12.6 22.1 23.0 10.9
40.0 27.1 19.6 15.9 25.8 21.9 13.7 25.1 23.0 12.7 23.8 25.2 11.0 22.3 27.4 9.5
42.0 28.1 19.8 16.5 26.8 22.0 14.1 26.1 23.2 13.1 24.7 25.4 11.3 23.1 27.6 9.7
025EW 44.0 29.2 19.8 17.0 27.8 22.1 14.5 27.0 23.3 13.4 25.5 25.7 11.5 24.0 28.0 10.0
46.0 30.2 19.9 17.4 28.8 22.3 14.9 27.9 23.5 13.7 26.3 25.9 11.8 24.8 28.4 10.2
48.0 31.2 19.9 18.1 29.7 22.4 15.4 28.9 23.6 14.2 27.4 26.2 12.2 25.8 28.7 10.5
50.0 32.4 20.1 18.6 30.7 22.6 15.8 29.9 23.8 14.6 28.4 26.5 12.5 27.5 29.1 10.9
40.0 30.4 21.7 16.1 28.8 24.3 13.8 28.1 25.5 12.8 26.6 27.9 11.1 24.9 30.3 9.6
42.0 31.4 21.9 16.6 30.0 24.4 14.2 29.1 25.7 13.2 27.6 28.1 11.3 25.8 30.6 9.8
030EW 44.0 32.6 22.0 17.1 31.0 24.5 14.6 30.2 25.8 13.5 28.5 28.5 11.6 26.8 31.0 10.1
46.0 33.8 22.1 17.6 32.2 24.6 15.0 31.3 26.0 13.9 29.4 28.7 11.9 27.8 31.5 10.3
48.0 34.9 22.1 18.2 33.2 24.8 15.5 32.4 26.2 14.3 30.7 29.0 12.3 28.8 31.7 10.6
50.0 36.2 22.2 18.7 34.3 25.0 15.9 33.5 26.3 14.7 31.7 29.3 12.6 30.8 32.3 10.9
40.0 38.8 26.8 16.8 36.6 29.7 14.3 35.5 31.1 13.3 33.5 33.9 11.5 31.3 36.6 9.9
42.0 40.2 27.0 17.2 38.0 30.0 14.7 36.9 31.4 13.7 35.1 34.3 11.8 32.5 37.1 10.2
040EW 44.0 41.6 27.2 17.8 39.3 30.2 15.1 38.0 31.7 14.0 35.9 34.6 12.1 33.7 37.6 10.4
46.0 43.1 27.5 18.3 40.8 30.5 15.5 39.6 32.0 14.4 37.3 35.0 12.5 35.0 38.0 10.6
48.0 44.6 27.6 18.8 42.2 30.7 16.0 41.0 32.3 15.2 38.7 35.4 12.7 36.3 38.5 11.0
50.0 46.1 27.7 19.3 43.7 31.0 16.5 42.5 32.6 15.2 40.0 35.8 13.0 37.5 38.9 11.3
40.0 44.9 30.4 17.1 42.4 33.7 14.6 41.1 35.4 13.6 38.8 38.5 11.7 36.3 41.6 10.2
42.0 46.5 30.7 17.6 44.0 34.0 15.0 42.7 35.6 14.0 40.7 39.0 12.0 37.6 42.1 10.4
045EW 44.0 48.2 30.9 18.2 45.5 34.3 15.4 44.0 36.0 14.3 41.6 39.3 12.4 39.1 42.7 10.7
46.0 49.9 31.2 18.7 47.2 34.6 15.9 45.9 36.4 14.7 43.2 39.8 12.7 40.5 43.2 10.9
48.0 51.6 31.3 19.2 48.8 34.9 16.4 47.5 36.7 15.5 44.8 40.2 13.0 42.0 43.7 11.2
50.0 53.4 31.5 19.7 50.6 35.2 16.8 49.2 37.0 15.5 46.3 40.6 13.3 43.5 44.2 11.5
40.0 52.5 38.1 16.0 49.6 42.3 13.7 48.2 44.3 12.7 45.4 48.2 11.0 42.4 52.1 9.5
42.0 54.4 38.5 16.5 51.5 42.6 14.1 50.0 44.6 13.1 47.6 48.8 11.3 44.0 52.8 9.8
050EW 44.0 56.4 38.7 17.0 53.3 43.0 14.5 51.5 45.1 13.4 48.7 49.3 11.6 45.7 53.5 10.0
46.0 58.5 39.1 17.5 55.3 43.3 14.9 53.7 45.6 13.8 50.5 49.8 11.9 47.4 54.1 10.2
48.0 60.4 39.2 18.0 57.2 43.7 15.3 55.6 46.0 14.5 52.4 50.4 12.2 49.2 54.8 10.5
50.0 62.5 39.5 18.5 59.2 44.1 15.7 57.6 46.4 14.5 54.2 50.9 12.5 50.9 55.4 10.8
40.0 59.7 41.4 16.8 56.3 45.9 14.3 54.7 48.1 13.3 51.5 52.4 11.5 48.2 56.6 9.9
42.0 61.8 41.8 17.2 58.5 46.3 14.7 56.7 48.5 13.7 54.1 53.0 11.8 50.0 57.3 10.2
060EW 44.0 64.1 42.0 17.8 60.5 46.7 15.1 58.5 49.0 14.0 55.3 53.6 12.1 51.9 58.1 10.4
46.0 66.4 42.4 18.3 62.8 47.1 15.5 61.0 49.5 14.4 57.4 54.1 12.5 53.8 58.8 10.6
48.0 68.6 42.6 18.8 64.9 47.5 16.0 63.2 50.0 15.2 59.6 54.7 12.7 55.9 59.5 11.0
50.0 71.0 42.9 19.3 67.2 47.9 16.5 65.4 50.4 15.2 61.6 55.3 13.0 57.8 60.2 11.3
Notes:
1. Bold box areas certified in accordance with ARI Standard 550/590-98.
2. Ratings based on HCFC-22, evaporator fouling of 0.0001, 2.4 gpm/ton; condenser fouling of 0.00025, 3 gpm/ton.
3. For 208V units multiply capacity and EER by 0.98.
4. Ratings are based on circuit #1 in lead position and circuit #2 in lag position.
5. Interpolation is allowed; extrapolation is not permitted. Consult McQuay for performance outside the ratings shown.
6. For LWT of 40°F and below please refer to Application Adjustment Factors section.
