Product Manual WHR-2 33
Electrical Data
Table 16, Compressor Amp Draw, WHR 017E - WHR 060E
Rated Load Amps (1) Locked Rotor Amps (2)
w/o Supplemental
Overloads
w/ Supplemental
Overloads
Across-The-Line
Start
Part Winding
Start
Unit
Size
Voltage
3-Phase
Freq
(Hz)
Circuit 1 Circuit 2 Circuit 1 Circuit 2 Circuit 1
Circuit
2
Circuit 1 Circuit 2
208 60 - - - 308 - 188 -
017 230 60 60 - - - 308 - 188 -
460 31 - - - 154 - 104 -
575 23 - - - 135 - 81 -
208 74 - - - 428 - 250 -
020 230 60 74 - - - 428 - 250 -
460 37 - - - 214 - 132 -
575 31 - - - 172 - 103 -
208 85 - - - 470 - 292 -
025 230 60 85 - - - 470 - 292 -
460 43 - - - 235 - 141 -
575 36 - - - 200 - 130 -
208 95 - - - 565 - 340 -
030 230 60 95 - - - 565 - 340 -
460 48 - - - 283 - 156 -
575 36 - - - 230 - 138 -
208 60 60 48 54 308 374 188 222
040 230 60 60 60 48 54 308 374 188 222
460 31 31 24 27 154 187 104 108
575 23 24 19 22 135 135 81 81
208 74 74 62 62 428 428 250 250
045 230 60 74 74 62 62 428 428 250 250
460 37 37 31 31 214 214 132 132
575 31 31 25 25 172 172 103 103
208 85 85 77 77 470 470 292 292
050 230 60 85 85 77 77 470 470 292 292
460 43 43 38 38 235 235 141 141
575 36 36 31 31 200 200 130 130
208 85 95 76 84 470 565 292 340
060 230 60 85 95 76 84 470 565 292 340
460 43 48 38 42 235 283 141 156
575 36 36 31 34 200 230 130 138
NOTES:
1. Compressor RLA values are for wire sizing purposes only and do not reflect normal operating current draw.
2. Compressor LRA values for part winding start are for the first winding.
3. Unit wire sizing amps are equal to 125% of the largest compressor-motor RLA plus 100% of RLA of all other loads in the circuit
including control transformer. Wire size amps for separate 115V control circuit power is 11 amps.
4. Single point power supply requires a single fused disconnect to supply electrical power to the unit.
5. Supplemental overloads are used in conjunction with standard inherent overload protection. The supplemental overloads:
• Reduce wire sizing amps
• Add additional protection
• Lower compressor amperage
6. Part Winding Start is a special option on 460 and 575 volt units.
