Product Manual WHR-2 57
EA Remote Condenser
Figure 10 Dimensions, WHR 017EA– WHR 030EA
Maximum Overall
Dimensions, in. (mm)
Chilled Water
Connections, in. (mm)
WHR
MODEL
NO. L W H Size A D
Inlet Liquid
Conn. Size
In. (mm)
Discharge
Conn. size
In. (mm) B
017EA
97 1/2
(2477)
25 1/2
(648)
46 1/2
(1181)
2 NPT (EXT)
(51)
13 1/2
(343)
17 3/4
(451)
7/8 O.D.
(22)
1 3/8 O.D.
(35)
43 3/4
(1111)
020EA
97 1/2
(2477)
25 1/2
(648)
46 1/2
(1181)
2 NPT (EXT)
(51)
13 1/2
(343)
17 3/4
(451)
7/8 O.D.
(22)
1 3/8 O.D.
(35)
43 3/4
(1111)
025EA
89
(2261)
28 3/4
(730)
47 1/2
(1207)
2 NPT (EXT)
(51)
7 1/2
(191)
18 3/4
(476)
7/8 O.D.
(22)
1 3/8 O.D.
(35)
38
(965)
030EA
99 1/2
(2527)
24
(610)
46 1/2
(1181)
2 NPT (EXT)
(51)
13 1/2
(343)
18 3/4
(476)
7/8 O.D.
(22)
1 5/8 O.D.
(41)
44
(1118)
