Product Manual WHR-2 71
Product Specifications
Water-Cooled, WHR 017 through 030
PART 1 - GENERAL
1.01 SUMMARY
Section includes design, performance criteria, refrigerants, controls, and installation
requirements for water-cooled reciprocating compressor packaged chillers.
1.02 REFERENCES
Comply with applicable Standards/Codes of ARI 550/590-98, ANSI/ASHRAE 15,
ASHRAE 90.1, ASME Section VIII, NEC, and OSHA as adopted by the State.
1.03 SUBMITTALS
A. Submit shop drawings and product data in accordance with contract
specifications.
B. Submittals shall include the following:
1. Dimensioned plan and elevation view drawings, required clearances, and
location of all field connections.
2. Summary of all auxiliary utility requirements such as: electricity, water,
compressed air, etc. Summary shall indicate quality and quantity of each
required utility.
3. Single line schematic drawing of the power field hookup requirements,
indicating all items which are furnished.
4. Schematic diagram of control system indicating points for field
interface/connection. Diagram shall fully delineate field and factory
wiring.
5. Manufacturer’s certification of factory run test of chiller unit signed by
company officer.
6. Installation manuals.
1.04 QUALITY ASSURANCE
A. Qualifications; Equipment manufacturer must specialize in the manufacture of the
products specified and have five years experience with the equipment and
refrigerant offered.
B Regulatory Requirements: Comply with the codes and standards specified.
C Chiller manufacturer must be ISO 9002 registered.
