McQuay WHR 017EW User Manual

Product Manual WHR-2 53
Dimensional Data
EW Water-Cooled
Figure 6, WHR 017EW through WHR 030EW
Maximum Overall
Dimensions
Chilled Water
Connections
Condenser Water
Connections
WHR
Model
Number
L W H SIZE A D N SIZE P
017EW
104 1/4
(2648)
26-1/4
(667)
46-1/2
(1181)
2 NPT (EXT)
(51)
13-1/2
(343)
17-3/4
(451)
51
(1295)
2 NPT (INT)
(51)
1-1/2
(38)
020EW
104-1/4
(2648)
26-1/4
(667)
46-1/2
(1181)
2 NPT (EXT)
(51)
13-1/2
(343)
17-3/4
(451)
51
(1295)
2 NPT (INT)
(51)
1-2
(38)
025EW
101-1/2
(2578)
29-1/2
(749)
47-1/2
(1207)
2 NPT (EXT)
(51)
7-1/2
(191)
18-3/4
(476)
51
(1295)
2 NPT (INT)
(51)
1-3/4
(44)
030EW
106
(2692)
29-1/2
(749)
46-1/2
(1181)
2 NPT (EXT)
(51)
13-1/2
(343)
18-3/4
(476)
51
(1295)
2 NPT (INT)
(51)
1-3/4
(44)
