34 Product Manual WHR-2
Table 17, Compressor Amp Draw, WHR 070E - WHR 120E
Rated Load Amps (1) Locked Rotor Amps (2)
w/o Supplemental
Overloads
w/ Supplemental
Overloads
Across-The-Line Part Winding
Unit
Size
Voltage
3-Phase
Freq.
(Hz)
Circuit 1 Circuit 2 Circuit 1 Circuit 2 Circuit 1 Circuit 2 Circuit 1 Circuit 2
208 122 122 115 115 650 650 400 400
070 230 60 122 122 100 100 594 594 340 340
460 60 60 50 50 297 297 195 195
575 42 42 40 40 245 245 152 152
208 135 135 124 124 754 754 463 463
080 230 60 127 127 108 108 594 594 340 340
460 64 64 54 54 297 297 195 195
575 48 48 43 43 245 245 152 152
208 135 162 124 147 754 1070 463 654
085 230 60 127 162 108 147 594 1070 340 654
460 64 82 54 74 297 535 195 330
575 48 68 43 59 245 405 152 262
208 162 162 147 147 1070 1070 654 654
090 230 60 162 162 147 147 1070 1070 654 654
460 82 82 74 74 535 535 330 330
575 68 68 59 59 405 405 262 262
208 74 , 85 74 , 85 62 , 76 62 , 76 428 , 470 428 , 470 250 , 292 250 , 292
095 230 60 74 , 85 74 , 85 62 , 76 62 , 76 428 , 470 428 , 470 250 , 292 250 , 292
460 37 , 43 37 , 43 31 , 38 31 , 38 214 , 235 214 , 235 132 , 141 132 , 141
575 31 , 36 31 , 36 25 , 31 25 , 31 172 , 200 172 , 200 103 , 130 103 , 130
208 74 , 95 74 , 95 62 , 84 62 , 84 428 , 565 428 , 565 250 , 340 250 , 340
100 230 60 74 , 95 74 , 95 62 , 84 62 , 84 428 , 565 428 , 565 250 , 340 250 , 340
460 37 , 48 37 , 48 31 , 42 31 , 42 214 , 283 214 , 283 132 , 156 132 , 156
575 31 , 36 31 , 36 25 , 34 25 , 34 172 , 230 172 , 230 103 , 138 103 , 138
208 122 , 74 122 , 74 115 , 62 115 , 62 650 , 428 650 , 428 400 , 250 400 , 250
110 230 60 122 , 74 122 , 74 100 , 62 100 , 62 594 , 428 594 , 428 340 , 250 340 , 250
460 60 , 37 60 , 37 50 , 31 50 , 31 297 , 214 297 , 214 195 , 132 195 , 132
575 42 , 31 42 , 31 40 , 25 40 , 25 245 , 172 245 , 172 152 , 103 152 , 103
208 122 , 74 122 , 74 115 , 62 115 , 62 650 , 428 650 , 428 400 , 250 400 , 250
115 230 60 122 , 74 122 , 74 100 , 62 100 , 62 594 , 428 594 , 428 340 , 250 340 , 250
460 60 , 37 60 , 37 50 , 31 50 , 31 297 , 214 297 , 214 195 , 132 195 , 132
575 42 , 31 42 , 31 40 , 25 40 , 25 245 , 172 245 , 172 152 , 103 152 , 103
208 122 , 74 122 , 122 115 , 62 115 , 115 650 , 428 650 , 650 400 , 250 400 , 400
120 230 60 122 , 74 122 , 122 100 , 62 100 , 100 594 , 428 594 , 594 340 , 250 340 , 340
460 60 , 37 60 , 60 50 , 31 50 , 50 297 , 214 297 , 297 195 , 132 195 , 195
575 42 , 31 42 , 42 40 , 25 40 , 40 245 , 172 245 , 245 152 , 103 152 , 152
NOTES:
1. Compressor RLA values are for wire sizing purposes only and do not reflect normal operating current draw.
2. Compressor LRA values for part winding start are for the first winding.
3. Unit wire sizing amps are equal to 125% of the largest compressor-motor RLA plus 100% of RLA of all other loads in the circuit
including control transformer. Wire size amps for separate 115V control circuit power is 11 amps.
4. Single point power supply requires a single fused disconnect to supply electrical power to the unit.
5. Supplemental overloads are used in conjunction with standard inherent overload protection. The supplemental overloads:
• Reduce wire sizing amps
• Add additional protection
• Lower compressor amperage
6. Part Winding Start is a special option on 460 and 575 volt units
