24 Product Manual WHR-2
Table 10, WHR 130EW - WHR 210EW, 60 Hz, SI Units
Entering Condenser Water Temperature (°C)
20°C (68°F) 25°C (77°F) 30°C (86°F) 35°C (95°F) 40°C (104°F)
Cap. PWR Cap. PWR Cap. PWR Cap. PWR Cap. PWR
WHR
SIZE
LWT
°C
kW kWi
COP
kW kWi
COP
kW kWi
COP
kW kWi
COP
kW kWi
COP
5.0 (41.0°F) 481.6 96.3 4.9 459.2 106.8 4.3 437.0 117.0 3.7 415.0 127.1 3.2 392.6 136.9 2.9
6.0 (42.8°F) 499.1 96.7 5.1 475.8 107.2 4.4 453.4 117.8 3.8 430.2 128.2 3.3 407.4 138.5 2.9
130EW
7.0 (44.6°F) 516.6 96.9 5.3 493.1 107.6 4.5 469.8 118.6 3.9 446.0 129.2 3.4 423.1 139.8 3.0
8.0 (46.4°F) 525.7 97.0 5.3 501.9 107.9 4.6 478.2 118.9 4.0 454.2 129.8 3.5 430.6 140.4 3.0
9.0 (48.2°F) 544.1 97.1 5.5 518.4 108.3 4.7 498.3 119.6 4.1 470.4 130.8 3.6 446.4 141.8 3.1
10.0 (50.0°F) 562.6 97.2 5.8 537.5 108.8 4.8 512.5 120.2 4.2 486.8 131.7 3.7 462.2 143.1 3.2
5.0 (41.0°F) 525.3 99.7 5.2 501.0 110.5 4.5 476.7 121.1 3.9 452.7 131.6 3.4 428.3 141.7 3.0
6.0 (42.8°F) 544.5 100.1 5.3 519.1 111.0 4.6 494.6 121.9 4.0 469.3 132.7 3.5 444.5 143.3 3.1
145EW
7.0 (44.6°F) 563.6 100.3 5.6 537.9 111.4 4.7 512.5 122.7 4.1 486.6 133.8 3.6 461.6 144.7 3.2
8.0 (46.4°F) 573.5 100.4 5.6 547.5 111.7 4.8 521.7 123.1 4.2 495.5 134.3 3.7 469.7 145.4 3.2
9.0 (48.2°F) 593.5 100.5 5.8 565.6 112.1 5.0 543.6 123.8 4.3 513.1 135.4 3.8 487.0 146.7 3.3
10.0 (50.0°F) 613.7 100.6 6.1 586.3 112.6 5.1 559.0 124.4 4.4 531.0 136.4 3.9 504.2 148.1 3.4
5.0 (41.0°F) 549.0 107.6 5.0 523.6 119.3 4.4 498.2 130.7 3.8 473.2 142.0 3.3 447.6 152.9 2.9
6.0 (42.8°F) 569.1 108.0 5.2 542.5 119.8 4.5 517.0 131.6 3.9 490.4 143.2 3.4 464.5 154.7 3.0
155EW
7.0 (44.6°F) 589.1 108.2 5.4 562.2 120.2 4.6 535.6 132.5 4.0 508.5 144.4 3.5 482.4 156.1 3.1
8.0 (46.4°F) 599.4 108.3 5.4 572.2 120.5 4.7 545.3 132.8 4.1 517.9 145.0 3.6 490.9 156.9 3.1
9.0 (48.2°F) 620.3 108.5 5.6 591.1 121.0 4.8 568.2 133.6 4.2 536.3 146.1 3.6 509.0 158.4 3.2
10.0 (50.0°F) 641.4 108.6 5.9 612.8 121.6 5.0 584.3 134.3 4.3 555.0 147.2 3.8 527.0 159.8 3.3
5.0 (41.0°F) 594.6 116.3 5.0 567.1 129.0 4.4 539.6 141.3 3.8 512.5 153.5 3.3 484.8 165.3 2.9
6.0 (42.8°F) 616.3 116.8 5.2 587.6 129.5 4.5 559.9 142.2 3.9 531.2 154.8 3.4 503.1 167.2 3.0
165EW
7.0 (44.6°F) 638.0 117.0 5.4 608.9 130.0 4.6 580.1 143.2 4.0 550.8 156.1 3.5 522.5 168.8 3.1
8.0 (46.4°F) 649.2 117.1 5.5 619.7 130.3 4.7 590.6 143.6 4.1 560.9 156.7 3.6 531.7 169.6 3.1
9.0 (48.2°F) 671.8 117.3 5.6 640.2 130.8 4.8 615.4 144.5 4.2 580.8 158.0 3.6 551.2 171.2 3.2
10.0 (50.0°F) 694.7 117.4 5.9 663.7 131.4 5.0 632.8 145.2 4.3 601.1 159.1 3.8 570.7 172.8 3.3
5.0 (41.0°F) 645.7 127.5 5.0 615.8 141.4 4.3 585.9 154.8 3.8 556.5 168.3 3.2 526.4 181.2 2.9
6.0 (42.8°F) 669.3 128.0 5.1 638.0 142.0 4.5 608.0 155.9 3.8 576.8 169.7 3.4 546.3 183.3 3.0
175EW
7.0 (44.6°F) 692.8 128.3 5.4 661.2 142.5 4.5 629.9 157.0 3.9 598.1 171.1 3.5 567.3 185.1 3.1
8.0 (46.4°F) 704.9 128.4 5.4 672.9 142.8 4.6 641.3 157.4 4.0 609.1 171.8 3.5 577.4 185.9 3.1
9.0 (48.2°F) 729.5 128.5 5.6 695.2 143.4 4.8 668.2 158.4 4.2 630.7 173.2 3.6 598.6 187.7 3.1
10.0 (50.0°F) 754.4 128.7 5.8 720.7 144.1 4.9 687.2 159.2 4.2 652.7 174.4 3.7 619.7 189.4 3.2
5.0 (41.0°F) 674.9 127.6 5.2 643.6 141.5 4.5 612.4 154.9 4.0 581.6 168.4 3.4 550.2 181.3 3.0
6.0 (42.8°F) 699.5 128.1 5.4 666.9 142.1 4.7 635.5 156.0 4.0 602.9 169.8 3.5 571.0 183.4 3.1
185EW
7.0 (44.6°F) 724.1 128.4 5.6 691.1 142.6 4.7 658.4 157.1 4.1 625.1 171.2 3.6 593.0 185.2 3.2
8.0 (46.4°F) 736.8 128.5 5.6 703.4 142.9 4.8 670.3 157.5 4.2 636.6 171.9 3.7 603.5 186.0 3.2
9.0 (48.2°F) 762.5 128.6 5.8 726.6 143.5 5.0 698.4 158.5 4.4 659.2 173.3 3.8 625.6 187.8 3.3
10.0 (50.0°F) 788.5 128.8 6.1 753.3 144.2 5.1 718.2 159.3 4.4 682.2 174.5 3.9 647.8 189.5 3.4
5.0 (41.0°F) 718.7 138.4 5.1 685.3 153.4 4.4 652.1 168.0 3.9 619.4 182.7 3.3 585.9 196.7 3.0
6.0 (42.8°F) 744.9 138.9 5.3 710.1 154.1 4.6 676.7 169.2 3.9 642.0 184.2 3.5 608.0 198.9 3.1
195EW
7.0 (44.6°F) 771.1 139.2 5.5 735.9 154.6 4.7 701.1 170.4 4.1 665.6 185.7 3.6 631.4 200.8 3.1
8.0 (46.4°F) 784.6 139.3 5.5 749.0 155.0 4.7 713.7 170.8 4.1 677.9 186.4 3.6 642.6 201.8 3.2
9.0 (48.2°F) 812.0 139.5 5.7 773.7 155.6 4.9 743.7 171.9 4.3 702.0 188.0 3.7 666.2 203.7 3.2
10.0 (50.0°F) 839.6 139.7 6.0 802.1 156.3 5.0 764.8 172.7 4.4 726.5 189.3 3.8 689.8 205.6 3.3
5.0 (41.0°F) 769.8 147.5 5.1 734.0 163.5 4.5 698.5 179.1 3.9 663.4 194.7 3.3 627.5 209.6 3.0
6.0 (42.8°F) 797.8 148.1 5.3 760.6 164.2 4.6 724.8 180.4 4.0 687.6 196.3 3.5 651.3 212.1 3.1
210EW
7.0 (44.6°F) 825.9 148.4 5.5 788.2 164.9 4.7 750.9 181.6 4.1 713.0 197.9 3.6 676.3 214.1 3.1
8.0 (46.4°F) 840.3 148.5 5.6 802.2 165.3 4.8 764.5 182.1 4.1 726.1 198.8 3.6 688.3 215.1 3.2
9.0 (48.2°F) 869.7 148.7 5.8 828.7 165.9 5.0 796.6 183.2 4.3 751.9 200.4 3.7 713.6 217.1 3.2
10.0 (50.0°F) 899.3 148.9 6.0 859.2 166.7 5.1 819.2 184.1 4.4 778.1 201.8 3.8 738.8 219.1 3.3
Notes:
1. Ratings based on HCFC-22 evaporator fouling of 0.0176, 0.043 L/s; condenser fouling of 0.044.
2. For 208V units multiply capacity and COP by 0.98.
3. Ratings are based on circuit #1 in lead position and circuit #2 in lag position.
4. Interpolation is allowed; extrapolation is not permitted. Consult McQuay for performance outside the ratings shown.
5. For LWT of 5°C and below please refer to Application Adjustment Factors section.
