36 Product Manual WHR-2
Table 19, Wire Sizing Amps, WHR 017E - WHR 080E
w/o Supplemental Overloads (1) w/ Supplemental Overloads (1)
Minimum Circuit Ampacity (MCA) Minimum Circuit Ampacity (MCA)
Multiple Point Power
Supply(3)
Multiple Point Power
Supply(3)
Unit
Size
Voltage
3-Phase
Freq.
(Hz)
Single Point
Power
Supply(2)
Circuit 1 Circuit 2
Single
Point
Power
Supply(2)
Circuit 1 Circuit 2
208 75 - - 60 - -
017
230 60 75 - - 60 - -
460 39 - - 30 - -
575 29 - - 24 - -
208 93 - - 78 - -
020
230 60 93 - - 78 - -
460 46 - - 39 - -
575 39 - - 31 - -
208 106 - - 95 - -
025
230 60 106 - - 95 - -
460 54 - - 48 - -
575 45 - - 39 - -
208 119 - - 105 - -
030
230 60 119 - - 105 - -
460 60 - - 53 - -
575 45 - - 43 - -
208 135 75 75 116 60 68
040
230 60 135 75 75 116 60 68
460 70 39 39 58 30 34
575 53 29 30 47 24 28
208 167 93 93 140 78 78
045
230 60 167 93 93 140 78 78
460 83 46 46 70 39 39
575 70 39 39 56 31 31
208 191 106 106 173 96 96
050
230 60 191 106 106 173 96 96
460 97 54 54 86 48 48
575 81 45 45 70 39 39
208 204 106 105 183 95 105
060
230 60 204 106 105 183 95 105
460 103 54 53 91 48 53
575 81 45 45 74 39 43
208 275 153 153 259 144 144
070
230 60 254 141 141 225 125 125
460 135 75 75 113 63 63
575 95 53 53 90 50 50
208 304 169 169 279 155 155
080
230 60 286 159 159 243 135 135
460 144 80 80 122 68 68
575 108 60 60 97 54 54
NOTES:
1. Unit wire sizing amps are equal to 125% of the largest compressor-motor RLA plus 100% of RLA of all other loads in the circuit including
control transformer. Wire size amps for separate 115V control circuit power is 11 amps.
2. Single point power supply requires a single fused disconnect to supply electrical power to the unit.
3. Multiple point power supply requires three independent power circuits with separate fused disconnects. (Two compressor circuits, one
control circuit.)
4. Supplemental overloads are used in conjunction with standard inherent overload protection. The supplemental overloads:
• Reduce wire sizing amps
• Add additional protection
• Lower compressor amperage
