MEA Incorporated | Hawk Actuator Instruction and Operation Manual
02/2018 10
1-5.3 Seat Protection
Electro-hydraulic actuation, such as the Hawk, can create extremely high seating thrust or torque. In some
cases, applying excessive actuator force while in the seated position can permanently deform the seating
surface, which may lead to process fluid leak by. The Hawk’s Safe Seat feature protects the valve in two
ways, by hydraulically limiting the maximum force the actuator applies to the valve in the seated position
and by maintaining a constant force on the seated valve. Since the Safe Seat is a hydraulic system it is
precise, adjustable, and rugged.
1-6 General Specifications
Construction
& Control
Actuator Type
Electro-Hydraulic, Self-Contained, Servo Motor Powered
Duty Cycle
100% Continuously
Modulating Duty Cycle
Power Supply
24-48 VDC, 1 PH, 50/60 HZ
110-120 VAC, 1 PH, 50/60 HZ
208-240 VAC, 1 PH, 50/60 HZ
208-240 VAC, 3 PH, 50/60 HZ
380-408 VAC, 3 PH, 50/60 HZ
Control Signal
4-20 mA Command Signal
24 VDC Pulse
115 VAC Pulse
Feedback Signal
4-20 mA Output
Feedback Type
4-20 mA Non-Contact Electromagnetic
Failure Mode
Loss of Signal
Loss of Power
Hydraulic Pressure
2000 psig
Hydraulic Fluid
Synthetic Gear Oil (AGMA Grade 4)
Hydraulic Pump
Positive Displacement Gear Type
Pump Capacity
0.168 gpm (Small)
0.554 gpm (Medium)
1.12 gpm (Large)
2.24 gpm (XL)
3.33 gpm (Mega)
6.61 gpm (Mega XL)
Stored Energy
Spring or Accumulator
Internal Reservoir
Integral, Sealed and Pressurized (10-20 psi)
Electrical Protection
Fused
IP Rating
IP Rating 66
